Mounting Devices
•
Door/Window Contact
1. The sensor should be on the frame while the magnet should be on the door/window.
Clean the mounting surface with a suitable degreaser agent and mount using the adhesive pads
Please note that some surfaces may be unsuitable for mounting using the adhesive pads. Please use
screwmounting in these cases.
5
6 7
a
b
or
Testing
The gap between the magnet and sensor should
be no more than 10mm when closed. Test to see
whether the magnet is in range of the sensor: before
mounting hold the magnet and sensor in place and
then pull them apart. If the sensor LED lights up it
implies the two items are within range.
