12
7. Pump Specifications
7.1 Engineering Data
Type SKR-110A50
Model No. 880631
Pump ratio 50 × 1
Material
connection
Discharge port G 1/4
Suction port
－
Air connection Air inlet G 1/4
Operating range
Supply air pressure
0.3～0.7 MPa
0.3 ～ 0.7 MPa
Noise dB(A) Max. 80.5
Operating temperature range
0～80 ℃
No. of cycle / liter 89
Dimensions (mm) 480×480×953
Mass (kg) 39
Accessories
Hi-pressure Hose (695034) 1/4×2.5m
Grease Gun (851985)
Air regulator with coupler (802553)
Follower plate (803481)
Above conditions
Air pressure 0.7 MPa
Material Grease NLGI-No.1
Oil Temperature 18.4 ℃
Pump outlet pressure 32～35 MPa
Delivery 3.3 L/min (2.94kg)
Cycle 276 cycle/min
Air consumption 930 L/min(ANR)
7.2 Performance Curve (only the pump) 7.3 Demensions
<Note>
The continuous pump operation should be avoided
if the desired delivery is in the range shaded in the
figure below.
480
480
953
To Next Page
