2-1
SPEC
E
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS 2
Item Unit
Model
Worldwide 150AET L150AET 175AET 200AET L200AET
USA C150TR ————
Canada —————
DIMENSION
Overall length
mm (in) 828 (32.6)
Overall width
mm (in) 600 (23.6)
Overall height
(L)
mm (in) 1,577 (62.1) — 1,577 (62.1) —
(X)
mm (in) 1,703 (67.0)
Boat transom height
(L)
mm (in) 508 (20.0) — 508 (20.0) —
(X)
mm (in) 635 (25.0)
WEIGHT
(with aluminum
propeller)
(L)
kg (lb) 178 (392.4) — 178 (392.4) —
(X)
kg (lb) 182 (401.2) — 182 (401.2) —
(with stainless steel
propeller)
(L)
kg (lb) 180 (396.8) — 180 (396.8) —
(X)
kg (lb) 184 (405.6) 186 (410.1) 184 (405.6) 186 (410.1)
PERFORMANCE
Maximum output
kW (hp) @
5,000 r/min
110.3 (150) 128.7 (175) 147.1 (200)
Full throttle operating
range
r/min 4,500 - 5,500
Maximum fuel
consumption
L (US gal,
lmp gal)/hr
@ 5,500 r/min
72 (19.0, 15.8) 75
(19.8, 16.5)
81 (21.4, 17.8)
POWER UNIT
Type
2 stroke - V
Number of cylinders
6
Displacement
cm
3
(cu. in) 2,596 (158.4)
Bore
×
stroke
mm (in) 90.0
×
68.0 (3.54
×
2.68)
Compression ratio
6.2 6.0 5.9
Compression pressure
kPa (kg/cm
2
) 745 (7.45) 892 (8.92)
Spark plugs (NGK)
BR8HS-10/BR8HS-10
*1
Number of carburetors
3
Enrichment system
Choke valve
Intake system
Reed valve
Induction system
Loop charge
Exhaust system
Through prop boss
Lubrication system
Pre-mix
Cooling system
Water
*1
: For china
