EMU01206
MAIN COMPONENTS
1 Top cowling
2 Cowling lock lever
3 Cooling water pilot hole
4 Tilt lock lever
5 Recoil starter handle
6 Gear shift lever
7 Throttle control grip
8 Throttle friction adjustment knob
9 Engine stop button/
Engine stop lanyard switch
0 Clamp screw
q Carrying handle
w Cooling water inlet
e Anti-cavitation plate
r Trim angle adjusting rod
t Clamp bracket
y Rope attachment
u Choke knob
i Fuel tank
o Fuel hose
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
