LIGHTING SYSTEM
7-17
EAS27260
TROUBLESHOOTING
Any of the following fail to light: headlight, tail/brake light.
TIP
• Before troubleshooting, remove the following part(s):
1. Seat
2. Front panel
3. Front fender
4. Rear fender
5. Side cover
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1. Check the each bulbs and bulb
sockets condition.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page 7-
32.
Replace the bulb(s) and bulb
socket(s).
2. Check the fuse.
Refer to “CHECKING THE FUSES”
on page 7-33.
Replace the fuse.
3. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 7-33.
• Clean the battery terminals.
• Recharge or replace the battery.
4. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 7-29.
Replace the main switch.
5. Check the light switch.
Refer to “CHECKING THE
SWITCHES” on page 7-29.
Replace the handlebar switch.
6. Check the headlight relay.
Refer to “CHECKING THE
RELAYS” on page 7-37.
Replace the headlight relay.
