Yamaha 212X - Wakeboard Tower (212 X Model)

2-22
2 FEATURES & FUNCTIONS
WAKEBOARD TOWER
(212X MODEL)
Severe injury or death can result if
you ignore any of the following:
• Maximum towing capacity:
1 Person, 350 lb. (158 kg) max.
• Make sure tow rope is securely
fastened to the tow pylon on the
tower.
• Donottowatubeorotherinflat-
able from the tower. Use the
transom cleat.
• Stay clear of the tow rope while
pulling a wakeboard rider or skier.
• Do not climb, hang, or sit on the
Wakeboard Tower.
• Makesureallknobssecuringthe
folding tower are tightened before
operation and check periodically
during use.
The Wakeboard Tower is provided as
an elevated tow point suitable for wake-
boards and similar towable recreational
equipment. The center pylon can be
used to attach a standard ski rope or
other tow rope.
Choose only accessories designed
for your boat's Wakeboard Tower. Your
Yamaha dealer has a variety of genu-
ine Yamaha accessories. Other acces-
sories may also be available on the
market. However, it is not possible to
test all non-Yamaha accessories, nor
have any control over the quality or
suitability of them. Choose a genu-
ine Yamaha accessory or one that is
equivalent in design and quality.
COLLAPSING THE
WAKEBOARD TOWER
The wakeboard tower can be collapsed
for boat storage in a building or under a
canopy or carport.
To avoid damage to the folding wake-
board tower, the boat, or both:
• Accidentally dropping the upper
tower section while collapsing or
raising it can damage the tower,
the boat, or both. An assistant
needs to support the upper tower
section during the procedure.
• Donotoperatetheboatortrans-
port it on the trailer with the tower
in the collapsed position to avoid
possible damage.
Collapsing
212X
1. Remove wakeboards and any other
accessories from the wakeboard
racks. Fold and secure the Bimini
top (if up).
2. Have the two short tower storage
supports ready. Remove the top and
two bottom inboard knobs from the
tower supports (three each side).
WARNING
