1-6
GB
For a greater operating load, a smaller-
pitch propeller is more suitable as it
enables the correct engine speed to be
maintained. Conversely, a larger-pitch
propeller is more suitable for a smaller
operating load.
Yamaha dealers stock a range of pro-
pellers, and can advise you and install a
propeller on your outboard that is best
suited to your application.
NOTE:
Select a propeller which will allow the
engine to reach the middle or upper half
of the operating range at full throttle with
the maximum boat load. If operating con-
ditions such as light boat loads then allow
the engine rpm to rise above the maxi-
mum recommended range, reduce the
throttle setting to maintain the engine in
the proper operating range.
1 Propeller diameter (in inches)
2 Propeller pitch (in inches)
3 Type of propeller (Propeller mark)
Propeller removal and installation; Refer
to propeller checking section in Chapter 4.
Recommended full throttle operating
range; Refer to SPECIFICATIONS, Page
4-1.
602024
7-1/4 x4 -A
1
23
602025
7-1/4 x7-1/4-BA
1
23
2
3/4/5
EMU00900
START-IN-GEAR PROTECTION
A Yamaha outboard motor attached the
label 1 has the start-in-gear protection
device(s). This engine can be started only
when it is in Neutral. Always select Neu-
tral before starting the engine.
6A1-9-7LA0-1 3/7/02 12:12 PM Page 18
