Yamaha 6H4L User Manual

6C-3
Outboard Rigging Guide - 2001
E
STEERING FRICTION
1. Adjust:
• Friction control nut 1
Steering friction to be;
THROTTLE FRICTION
1. Adjust:
• Friction control nut 1
Throttle friction to be;
PTT SWITCH
ENGINE START
Increased
Decreased
Increased
Decreased
Operation steps:
• Turn the main switch to “ON.”
• Push and hold the switch.
UP Tilt up
DN Tilt down
Operation steps:
• Install the lanyard lock plate 1 to engine
stop switch 2.
• Turn the main switch to “ON” from “OFF”
then to “START.”
