Yamaha 70BETO S-transom User Manual

7-26
(*5)
35
ECM ECM ECM
P
C
S
(*1)
47
18
Fuel tank 2 Fuel tank 1
USB
21
(*4)
20
GPS
(*3)
Freshwater
tank
Sewage
tank
22
(*2)
To NMEA2000 Network
CENTER enginePORT engine STBD engine
(*1) For previous digital electronic controlled engine (*2) For previous network system (6Y8) (*3) Engine selection for tachometer (*4) Requires 3 pcs includig its related parts (*5) Connect the sensor ground leads to the ground (negative circuit on the battery)
2
16 16
53
48
4
23
24
26
25
6
19
1
12
15
13
13
11
5
12
13
13
10
(+) (GND)
NETWORK WIRING DIAGRAMS
SINGLE STATION W/ 6Y9 GAUGE TRIPLE ENGINE APPLICATION

Yamaha 70BETO S-transom Specifications

General

Horsepower	70 hp
Starting System	Electric
Full Throttle RPM Range	4500 - 5500 rpm
Fuel Induction	Carburetor
Fuel Type	Gasoline
Shaft Length	S
Steering	Remote
Trim System	Power Trim & Tilt
Exhaust	Through Propeller Exhaust
Oil Injection	Yes
