Yamaha 70BETO S-transom User Manual

7-28
35
ECM ECM ECM
P
C
S
(*1)
(*2)
47
22
16 16
16
16
53
48
19
1
13
12
GPS
Fuel tank 2 Fuel tank 1
9
SPEED
FUEL MGT
TAC HTAC HTAC H
13
(*1) For previous digital electronic controlled engine (*2) For 6Y9 network system
13
12
13
15
12
13
(GND)
(+)
NETWORK WIRING DIAGRAMS
SINGLE STATION W/ 6Y8 GAUGE TRIPLE ENGINE APPLICATION

Yamaha 70BETO S-transom Specifications

General

Horsepower	70 hp
Starting System	Electric
Full Throttle RPM Range	4500 - 5500 rpm
Fuel Induction	Carburetor
Fuel Type	Gasoline
Shaft Length	S
Steering	Remote
Trim System	Power Trim & Tilt
Exhaust	Through Propeller Exhaust
Oil Injection	Yes
