peterschneiderSep 6, 2025
How to setup Yamaha 55BED S-transom Outboard Motor tachometer to show the oil pressure?
- JJerry GutierrezSep 6, 2025
Select the oil press. display.
How to setup Yamaha 55BED S-transom Outboard Motor tachometer to show the oil pressure?
Select the oil press. display.
What to do if the Yamaha Outboard Motor gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or, if necessary, replace the gauge itself.
Why Yamaha Outboard Motor illumination does not light?
If the illumination does not light, it could be due to a lack of electrical power or a damaged gauge. You should try replacing the fuse, connecting the couplers securely, replacing the damaged wire or hub, or replacing the gauge.
How to fix Yamaha Outboard Motor tachometer showing incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong (especially for multi-applications). To correct this, push the 'SET' button for 10 seconds to default the engine number, then memorize each engine number again.
What causes Yamaha Outboard Motor fuel management gauge to show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting may be wrong (specifically for SQR Fuel mgt Gauge). Fill the tank with fuel, and set the correct fuel tank capacity.
What to do if Yamaha 55BED S-transom gauge shows “----”?
If the gauge displays '----', it indicates that the digital signal is not being received. Check that the couplers are securely connected and replace any damaged bus wires or hubs.
What to do if my Yamaha 55BED S-transom Outboard Motor speedometer shows the incorrect fuel level?
If the speedometer shows an incorrect fuel level, the fuel sensor selection is likely wrong. You should set up the fuel sensor to the correct resistance.
Why Yamaha 55BED S-transom Outboard Motor boat speed and/or coolant pressure gauge does not show?
If the boat speed and/or coolant pressure gauge does not show, it is likely that the optional sensor has not been installed. Install the optional sensor.
What causes Yamaha Outboard Motor gauge response to be poor or down?
If the gauge response is poor or down, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Try replacing the unit or removing the heavy signal output unit.
What to do if Yamaha 55BED S-transom trim gauge always shows fully tilted up position?
If the trim gauge always shows a fully tilted-up position, the trim sender signal is not being received. Connect the pink lead connectors to each other.
General| Brand | Yamaha |
|---|---|
| Model | 55BED S-transom |
| Category | Outboard Motor |
| Language | English |
Defines WARNING for hazardous situations and NOTICE for precautions to avoid damage.
Details the steps for safely removing the outboard motor from its steel crate.
Provides instructions on how to properly mount the outboard motor onto the boat transom.
Provides WOT RPM ranges for selecting appropriate propellers for different engine models.
Details various types of Yamaha remote controls and their applications.
Introduces the multi-function tiller handle and its electrical functions.
Provides instructions for mounting gauges, including analog gauge illumination.
Covers speedometer types, applications, dimensions, and tube routing.
Describes the functions and applications of the fuel management gauge.
Details the setup procedure for the fuel management gauge, including switch settings and compensation.
Explains analog trim meter applications, dimensions, and adjustment procedures.
Covers coolant pressure meter applications, additional parts, dimensions, and installation.
Details coolant temperature meter applications, additional parts, dimensions, and sensor installation.
Provides wiring diagram samples for various configurations.
Summarizes the functions of digital network gauges for various engine models.
Lists engine models compatible with the digital network premium gauge.
Shows wiring for single engine applications with 6Y9 gauges and 6X6 binnacle mount controls.
Illustrates wiring for single engine applications with 6Y8 gauges and 6X6 binnacle mount controls.
Details wiring for single engine applications with 6Y9 gauges and 6X7 concealed controls.
Shows wiring for single engine applications with 6Y8 gauges and 6X7 concealed controls.
Provides wiring diagrams for twin engine applications with 6Y9 gauges.
Illustrates wiring diagrams for twin engine applications with 6Y8 gauges.
Details wiring diagrams for triple engine applications with 6Y9 gauges.
Shows wiring diagrams for triple engine applications with 6Y8 gauges.
Wiring diagrams for dual station single engine applications with 6Y9 gauges.
Illustrates wiring diagrams for dual station single engine applications with 6Y8 gauges.
Wiring diagrams for dual station quad engine applications with 6Y9 gauges.
Provides guidance on selecting appropriate batteries based on engine model and capacity.
