Yamaha 8A - Procedure for Tilting up

3-22
E
304014*
EMU00288
PROCEDURE FOR TILTING UP
1) Place the gear shift lever in Neutral.
310012
N
2) Remove the fuel line connection from
the motor.
3) Hold the rear of the top cowling with
one hand and fully tilt the engine up.
4) Push the tilt support knob into the
clamp bracket.
PROCEDURE FOR TILTING DOWN
1) Slightly tilt up the engine.
2) Pull out the tilt support knob.
3) Tilt down the engine slowly to its
home position.
