Equipment operation
62
(3) Lower the wakeboard tower, and then in-
stall the short tower storage supports.
1 Wakeboard tower
1 Short tower storage support
To set up the wakeboard tower:
(1) Remove the short tower storage sup-
ports, and then lift the wakeboard tower.
(2) While supporting the wakeboard tower,
lift each support pole and install the upper
support knob to the pole.
(3) Tighten the lower support knob on both
sides of each support pole.
Bimini top (AR190)
Setting up the bimini top
To set up the bimini top:
(1) Unfasten the buckles and pull the bimini
top toward the bow.
1 Buckle
(2) While supporting the bimini top, unhook
the forward support poles from the front
pole.
1 Bimini top
2 Forward support pole
1
1
1
2
1
SportsBoat.book Page 62 Monday, October 31, 2011 4:12 PM

Yamaha AR190 2012 Specifications

General

Length	19' 2"
Fuel Capacity	30 gal
Horsepower	180 hp
Impeller	3-blade, stainless steel
Engine Type	4-cylinder
Draft	15 in
