10-1
EBU00428
SPECIFICATIONS
Model YFZ350
Dimension:
Overall length 1,855 mm (73.0 in)
Overall width 1,100 mm (43.3 in)
Overall height 1,080 mm (42.5 in)
Seat height 800 mm (31.5 in)
Wheel base 1,280 mm (50.4 in)
Ground clearance 135 mm (5.31 in)
Minimum turning radius: 3,600 mm (141.7 in)
Basic weight:
With oil and full fuel tank 187 kg (412 lb)
Engine:
Type Liquid cooled, 2-stroke
Cylinder arrangement Forward inclined parallel 2-cylinder
Displacement 347 cm
3
(21.17 cu.in)
Bore × Stroke 64 × 54 mm (2.52 × 2.13 in)
Compression ratio 6.5 : 1
Starting system Kick starter
Lubrication system Premix
10
