Appendix
Assembling the Clavinova
Remove all parts from the package and make sure you have all of the items.
*This illustration shows model CLP-440.
CLP-440/430 Assembly
A
B
C
DE
Foamed styrol pads
Remove foamed styrol pads from the package, position them on
the floor, then place A on top of them.
Position the pads so that they will not hide the connectors on the
bottom of A.
A bundled pedal cord is attached to the reverse side.
6 x 20 mm long screws x 4
6 x 16 mm short screws x 6
4 x 12 mm thin screws x 2
4 x 10 mm thin screws x 2
Cord holders x 2
Headphone hanger
Power cord
Assembly parts
Headphone hanger
4 x 20 mm tapping screws x 4
