Yamaha Disklavier E3 Series - Part Names

4
1. Part Names
■Control Unit—Front Panel
■Control Unit—Rear Panel
■Remote Control
①[ON/OFF] button
②USB port
③Remote control sensor
④CD drive
①USB TO DEVICE port
②LAN port
③OUTPUT jacks
④ANALOG MIDI IN jacks
①[ON/STANDBY] button
②Number keypad
③[SYSTEM] button
④[VOICE] button
⑤[RECORD] button
⑥[PLAY] button
⑦[REVERSE]/[FORWARD] buttons
⑧Cursor buttons
⑨[BACK] button
⑩[VOLUME] button
⑪[TEMPO] button
⑫[TRANSPOSE] buttons
⑬[INTERNET] button
⑭[SEARCH] button
⑤CD eject button
⑥[PLAY/PAUSE] button
⑦[STOP] button
⑧[RECORD] button
⑨[SELECT] button
⑩Cursor/[ENTER] buttons
⑪Display
⑫Dial
⑮[SETUP] button
⑯[METRONOME] button
⑰[REPEAT] button
⑱[A-B] button
⑲[PART SELECT] buttons
⑳[PAUSE] button
○
21
[STOP] button
○
22
[ENTER] button
○
23
[FUNC.] button
○
24
[SELECT] button
○
25
[+/YES]/[-/NO] buttons
○
26
[BALANCE] button
○
27
Color buttons
⑨USB TO HOST port
⑩MIDI OUT terminal
⑪MIDI IN terminal
⑤OMNI(SYNC) OUT jacks
⑥OMNI(SYNC) IN jacks
⑦TO PIANO connectors
⑧DC-IN 12V connector
2
