Yamaha Disklavier E3 Series - Page 48

No. Part Name Part Number Remarks
12
CSP Unit WQ087100
13
CSP Circuit Board WR673600
14
Key Drive Unit WQ5508X0
15
EKD1 Circuit Board WK726300 for key #57-88
16
EKD2 Circuit Board WK726500 for key #1-10
17
EKD3 Circuit Board WK726700 for key #11-42
18
EKD4 Circuit Board WN743300 for key #43-56
Solenoid Ass’y WS563900 Odd key
- do - WQ553200 Even key
19
Pedal Drive Unit WQ088300
20
PDU Circuit Board WR768200
21
Hammer Sensor Ass’y WQ086700
22
Hammer Sensor Circuit Board WN739200
23
Key Sensor Unit WQ088700
24
Key Sensor Circuit Board WN594200
25
PS Unit WR128500
26 Power Supply Unit（48V）
WC814600
27 Power Supply Unit（12V）
WC702500
28
Switch Box Unit WQ573200
29
Pedal Sensor Unit WQ198500
30
AC Cable VT119800
31
MD Unit V7981600
32
Remote Controller WN570900
35
Hammer Shutter V9071600
36
Key Shutter Ass’y V7978300
37
Key Shutter, Gray Scale V797780R
38
Key Shutter Block V797790R
Piano Parts
No. Part Name Part Number Remarks
33
Shank Stopper V7978900
34
Holder, Shank Stopper V7981500
46
