Yamaha Disklavier E3 Series - Page 50

Electrical Parts
No. Part Name Part Number Remarks
1
Control Unit
WN755500 DKC-800
２
CTRL Circuit Board WN507700
３
MC Circuit Board WN507900
４
APE Circuit Board WN507800
５
USB Circuit Board WN757300
６
PANEL Circuit Board WN757600
７
ENCD Circuit Board WN757000
８
JACK Circuit Board WN708200
９
REG Circuit Board WN508400
10 1/2” CD-ROM WN735100
11 EXG Circuit Board WN767400
12
CSP Unit
WN802300
13 CSP2 Circuit Board WN671300
14
Key Drive Unit
WN651600
15 EKD1 Circuit Board WK726300 for Key #57-88
16 EKD2 Circuit Board WK726500 for Key #47-56
17 EKD3 Circuit Board WK726700 for Key #15-46
18 EKD4 Circuit Board
W
Ｎ743300
for Key #1-14
19 Solenoid Assy WN693200 common
20
Pedal Drive Unit
WN651700
21 Solenoid, Damper WN738400
22 Solenoid, Shift WN738500
23 Pedal Drive Circuit Board WN738700
24
Hammer Sensor Unit
25 Hammer Sensor Circuit Board
26 Hammer Emission Circuit Board
27
Key Sensor Unit
WN651300
28 KS2 Circuit Board WN594200 Key Sensor Board
29
PS Unit
WN705200
30 Power Supply Unit, 48V WN702400
31 Power Supply Unit, 12V WN702500
32 Switch Box Unit
33 AC Cable
34 MD Unit
35 Hammer Shutter
36
Key Shutter Assy
WC368000
37 Key Shutter, Gray Scale WC36820R
38 Key Shutter Brock V886890R
39
Remote Controller
WN570900
48
