2
ABCDEFGH I J
1
3
4
5
7
RX-V530/RX-V530RDS/HTR-5550/HTR-5550RDS/DSP-AX530
RX-V430/RX-V430RDS/HTR-5540/HTR-5540RDS/DSP-AX430
6
54
Ref. No. Location
D301 C2
D302 D2
D303 F3
D304 F3
D305 F3
D306 G3
D307 G3
D308 G3
D309 F3
D310 G3
D311 F3
D312 E2
D313 F2
D314 H5
D315 G5
IC301 H3
IC302 C3
IC303 E3
IC304 D3
IC305 E2
Q307 F2
Q308 G3
Q309 F3
■ PRINTED CIRCUIT BOARD (Foil side)
1
14
85
14
8
18
16 9
5
24
65
80
25
40
41
64
FUNCTION (1) P. C. B.
(Surface Mount Device)
1
30
81
100
31
50
51
80
P.W.B version B & C only
Circuit No. J U, C R, T, K A, L B, G
R382 X X O O O
R386 X O O X X
R409 O O O O X
X: NOT USED
O: USED / APPLICABLE
• Semiconductor Location
