Yamaha DTX6 - Page 11

11
ELECTRONIC DRUM RACK Owner’s Manual
2. Attach a tom holder to each of the three tom clamps.
2-1. Loosen the bolt on the tom clamp.
2-2. Insert the tom holder.
2-3. Securely tighten the bolt on the tom clamp.
3. Attach a cymbal holder to each of the two cymbal clamps.
3-1. Loosen the bolt on the cymbal clamp.
3-2. Insert the cymbal holder.
3-3. Securely tighten the bolt on the cymbal clamp.
CAUTION
Take special care with tom holders as they have sharp tips that could cause injury.
To m c la m p
Tom holder
Bolt
Cymbal holder
Bolt
Cymbal holder
Bolt
Cymbal clampCymbal clamp
Sleeve (black)
 On the left arm  On the right arm
Sleeve (black)
