9-28
OTHER RIGGING KIT CONTENTS
TILT LIMIT SWITCH KIT 3 (FOR US, CA, EU, ANZ, JP, RUS, TUR)
P/N: 6D8-825EY-00
Applicable models:
Kit contents:
* For installation, see the service manual and/or installation manual.
TILT LIMIT SWITCH KIT 4 (FOR US, CA, EU, ANZ, JP, RUS, TUR)
P/N: 6C5-825EY-00
Applicable models:
Kit contents:
* For installation, see the service manual and/or installation manual.
Global model F75B F80B F90B F100D
US/CA Model F75A F90A
Part No. Part name Q’ty Remarks
6D8-825E0-00 Tilt limit SW ASSY 1
97595-06512 Bolt w/ washer 2
90159-05059 Screw 1
90387-05004 Collar 1
90465-11M10 Clamp 4
Global model F40G F40H F50H FT50J F60F FT60G F70A
US/CA model F50B T50B F60B T60B F70A
Part No. Part name Q’ty Remarks
6C5-825E0-00 Tilt limit SW ASSY 1
90109-06M88 Bolt 2
92990-06100 Washer 2
90159-05059 Screw 1
90387-05004 Collar 1
90465-11M10 Clamp 5
90465-13M18 Clamp 3

Yamaha E15DMH Specifications

General

Engine Type	2-Stroke
Displacement	246 cc
Fuel System	Carburetor
Starting System	Manual
Bore x Stroke	56 mm x 50 mm
Max Output	15 hp
Max Power Output	11.0 kW / 5, 000 rpm
Full Throttle Operating Range	4500 - 5500 rpm
Weight	37 kg
Gear Ratio	2.08
Steering	Tiller
Trim System	Manual
Recommended Fuel	Regular Unleaded Gasoline
Recommended Engine Oil	Yamalube 2-Stroke Oil
