97
E
F75B, F80B, F90B, F100D
No. Part name Q’ty Remarks
1 Tiller handle assembly 1
2 Protector 1
3 Self-locking nut 2
4 Bracket 1
5 Stud bolt 2
6Grommet 1
7 Plastic tie 1
8 Hose guide 1
9 Bolt with washer 2
10 Stay 1
11 Corrugated tube 1 (230 mm (9.1 in))
12 Corrugated tube 1 (65 mm (2.6 in))
13 Plastic tie 5
8
9
10
5
4
3
2
6
7
11
12
13
1
9
TillerHandle.book Page 97 Friday, April 12, 2013 3:19 PM
