Yamaha F40A - Chapter 2 Basic Components

Chapter 2
BASIC COMPONENTS
MAIN COMPONENTS..............................2-1
OPERATIONS OF CONTROLS AND
OTHER FUNCTIONS ................................2-2
Fuel tank.................................................2-2
Remote control......................................2-3
Tilt support lever...................................2-7
Trim angle adjusting rod......................2-7
Top cowling lock lever..........................2-7
Trim tab..................................................2-8
Power trim/tilt switch............................2-9
Tachometer..........................................2-10
Trim meter...........................................2-10
Tilt lock mechanism............................2-11
WARNING SYSTEM ..............................2-12
Overheat warning ...............................2-12
Low oil pressure warning ..................2-13
GB
62Y-9-78 (E,F,ES) 2 5/25/00 4:08 PM Page 2
