What to do if my Yamaha F70AET Outboard Motor gauge display does not wake up?
If the gauge display doesn't wake up, it could be due to a lack of electrical power or a damaged gauge. Try these steps: replace the fuse, securely connect the couplers, replace any damaged wires or hubs, or replace the gauge itself.
Why is the illumination not lighting on my Yamaha F70AET Outboard Motor gauge?
If the illumination isn't lighting, it could be because of a power issue or a damaged gauge. You should try replacing the fuse, ensuring the couplers are securely connected, replacing any damaged wires or hubs, or replacing the gauge.
Why does my Yamaha F70AET Outboard Motor fuel management gauge show incorrect fuel consumption?
If the fuel management gauge shows incorrect fuel consumption, the engine recognition may be wrong. To resolve this, default the engine number. Then, turn the key switch on in order from the portside engine to re-memorize each engine number.
How to fix a Yamaha Outboard Motor tachometer that shows incorrect engine RPM?
If the tachometer shows an incorrect engine RPM, the engine recognition might be wrong. Push the SET button for 10 seconds to default the engine number, and then memorize each engine number again.
What to do if my Yamaha F70AET speedometer shows the incorrect fuel level?
If the speedometer shows an incorrect fuel level, the fuel sensor selection is likely wrong. You should set up the fuel sensor to the correct resistance.
What does it mean when my Yamaha Outboard Motor gauge shows “----”?
If the gauge shows “----”, it indicates that the digital signal is not being received. Make sure the couplers are securely connected and replace any damaged bus wires or hubs.
Why does my Yamaha F70AET fuel management gauge show incorrect remaining fuel?
If the fuel management gauge shows incorrect remaining fuel, the fuel capacity setting is probably wrong. Fill the tank with fuel, and then set the correct fuel tank capacity.
Why does my Yamaha F70AET Outboard Motor trim gauge show the incorrect position?
If the trim gauge shows an incorrect position, the initial position setting might be wrong, or the trim sensor could be damaged. Put the motor in the fully trimmed-in position and reset the initial (zero) trim angle. If that doesn't work, replace the trim sensor.
Why is my Yamaha Outboard Motor gauge operating unstably?
If the gauge operates unstably, it's likely that the resistor isn't connected to the ending hubs. Connect the gray 6-pin cap to the ending multi-hubs to resolve this.
Why is the Yamaha F70AET Outboard Motor gauge response poor?
If the gauge response is poor, a market obtainable unit connected to the system may have failed, or the signal volume has exceeded 50% of the capacity. Replace the faulty unit or remove the heavy signal output unit.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates special precautions that must be taken to avoid damage to the products or other property.
Step-by-step guide for safely removing the outboard motor from its steel crate.
Instructions on properly mounting the outboard motor for optimal performance and reliability.
Details and dimensions for mounting the remote oil tank for specific engine models.
Provides definitions for symbols used to denote outboard motor dimensions.
Details types of Yamaha propellers designed to match outboard motor characteristics.
Guidance on selecting the appropriate propeller based on application and load.
Explains throttle control systems (Push To Open/Pull To Open) and model compatibility.
Provides examples for measuring and selecting appropriate remote control cable lengths.
Describes the functions and electrical features of the multi-function tiller handle.
Provides general torque table for steering friction kit components.
Procedures for mounting gauges, including orientation and clearance requirements.
Details analog tachometer applications and compatible models.
Describes speedometer types and applications, including digital and analog models.
Covers fuel management gauge functions, types, applications, kit contents, and wiring.
Covers coolant temperature meter applications, additional parts, dimensions, and installation.
Lists models compatible with digital network gauges for 4-stroke and HPDI engines.
Lists various wire harness types including main bus, pigtail, and system power supply wires.
Table of common troubleshooting symptoms, causes, measures, and notes for gauge issues.
Lists models compatible with Digital Network Premium Gauge (6Y9) new network system.
Describes the application of the premium gauge with TFT-LCD screen and arrow keys.
Provides guidance on selecting batteries based on engine model, capacity, and charging voltage.
Explains battery wiring for isolator-equipped models and twin engine applications.
Explains how model names are structured, including prefix, model, transom length, and serial number.
Checklist for pre-delivery inspection to enhance customer satisfaction and ensure proper operation.
Lists contents for conventional rigging kits, including digital tachometer and speedometer kits.
Lists contents for immobilizer rigging kits for different regions and engine configurations.
General| Engine Type | 4-Stroke |
|---|---|
| Displacement | 996 cc |
| Max Output | 70 hp |
| Starting System | Electric |
| Cylinder Configuration | Inline 4 |
| Lubrication System | Wet Sump |
| Gear Shift | F-N-R |
| Steering | Remote |
| Fuel System | Electronic Fuel Injection (EFI) |
| Operating Range | 5000 - 6000 RPM |
| Ignition System | TCI (Transistor Controlled Ignition) |
| Exhaust | Through Propeller |
| Shaft Length | S: 508 mm, L: 635 mm |
| Oil Capacity | 4.0 L |
| Gear Ratio | 2.33:1 |
