3-18

REMOTE SWITCH APPLICATIONS

TRIPLE IG SWITCH

Ref. No. Part No. Description

1 6X5-82570-01 For Digital network gauge

2 6X6-82570-20 For F350/F300/F250 [Digital Electronic Control], 2nd helm (dual-station)

Cut out shaded areaCut out shaded area

128 (5.04)

25.9 (1.02)

24.25 (0.95)

93 (3.66)

(2.13)

5.5 (0.22)

110 (4.33)

145 (5.71)

510 (20.08)

370 (14.57)

*130 (5.12)

* Minimum mounting depth (for reference)

130 (5.12)

184 (7.24)

Cut out shaded areaCut out shaded area

167 (6.57)

25 (0.98) 25 (0.98)

113 (4.45)

24 (0.94)

52.4

(2.06)

5.5 (0.22)

mm (in.)

140 (5.51)

86 (3.39)

YBr

mm (in.)
