Yamaha FX Audio Kit - Preparation and Installation Steps; Preparation; Step 1: Base and Extension Removal; Step 2: Install Mounting Base

7/2019 F3X_H81E0_T0_A MANUAL, INSTALL
AUDIO SET
Page 2 of 3
©Yamaha Motor Corporation, U.S.A. All rights reserved.
PREPARATION:
• Ensure the WaveRunner
®
is on a secure stand or trailer and level surface.
• Clean all mounting surfaces before beginning installation.
• It is recommended to have the factory service manual available for reference.
INSTALLATION:
1. Remove the Multi-Mount Base and Cup Holder Extension, if fitted. Retain the hardware to use later in the install.
3. Tighten screws to 44 in-lb (5Nm).
2. Install EcoXGear mounting base into the cup
holder on the unit. Secure with the screws retained in
Step 1. If you do not have a Cup Holder Extension,
use the three flanged button head screws supplied
with this kit.
