2-21
E
EJU20730
Multifunction meter
This meter contains the following func-
tions for help and convenience in operating
the watercraft.
1
Tachometer
2
Speedometer
3
Hour meter/Voltmeter
4
Fuel meter
5
“L-MODE” indicator light
6
Warning light
7
Fuel warning indicator
8
Engine overheat warning indicator
9
Oil pressure warning indicator
0
Check engine warning indicator
A
Select button
B
“SECURITY” indicator light
@
Do not run the engine for more than
15 seconds when checking the operation
of the meter on land. The engine could
overheat.
@
N
TE:
@
●
When the engine is started, all displays
light up for 2 seconds and then the meter
starts to operate normally.
●
The current display will continue to oper-
ate for 25 seconds after the engine stops.
@
UF1S11.book Page 21 Monday, August 2, 2004 3:06 PM
