36
Pre-operation checks
Hydraulic fluid level
Inspect the amount of fluid in the steering pump reservoir when the steering wheel is being
turned. When the fluid level is below the “MIN” mark, replenish until the fluid is between the
“MIN” and “MAX” marks.
1. “MAX” mark
2. “MIN” mark
Steering bypass valve
Check that the steering bypass valve lever is in the closed position.
For maintenance and emergency access, have your dealer show you where the steering
pumps and steering bypass valves are located in the boat.
OPEN
CLOSED
WARNING
214465
STEERING BYPASS VALVE
For emergency return-to-port
steering only. Read User’s Manual.
Improper valve use can
Close valve before
starting engine(s).
result in loss of control.
0KAW_dtp_data_US.book Page 36 Monday, December 17, 2012 3:35 PM
