Controls and instruments
DESCRIPTION
2-3
2
17. Rear brake lever (page 6-11)
18. Left handlebar switch (page 3-3)
19. Speedometer (page 3-2)
20. Turn signal indicator light (page 3-1)
21. High beam light (page 3-1)
22. Oil level warning light (page 3-1)
23. Coolant temperature warning light (page 3-1)
24. "TRIP" button (page 3-2)
25. Fuel gauge (page 3-3)
26. Front brake lever (page 3-4 )
27. Right handlebar switch (page 3-3)
28. Turn signal switch (page 3-3)
29. Horn switch (page 3-3)
30. Main switch (page 3-1)
31. Coolant level gauge window (page 6-7)
