Components
31
EMU38593
Remote control transmitter (if
equipped)
The lock and unlock modes of the Yamaha
Security System are selected using the re-
mote control transmitter. While the engine is
running, input from the remote control trans-
mitter is not received.
Store the remote control transmitter carefully
so it will not be lost.
ECM02101
The remote control transmitter is not
completely waterproof. Do not sub-
merge the transmitter or operate it un-
derwater. If the transmitter is
submerged, dry it with a soft, dry cloth,
SET
MENU
CANCEL
1
4
6
3
2
5
7
SET MODE
SET MODE
ZMU07205
1. Tachometer unit (Square type)*
2. Tachometer unit (Round type)*
3. Speedometer unit (Square type)*
4. Speed & fuel meter unit (Square type)*
5. Speed & fuel meter unit (Round type)*
6. Fuel management meter unit (Square type)*
7. 6Y9 Multifunction Color Gauge*
6CE-9-36-1E0.book 31 ページ ２０１４年１１月２８日 金曜日 午後２時５５分
