Maintenance
90
7. Remove the apron from starboard side
as shown in the illustration.
8. Remove the oil filler cap.
9. Prepare a suitable container that holds a
larger amount than the engine oil capac-
ity. Remove the drain screw and gasket
while holding the container under the
drain hole. Let the oil drain completely.
Wipe up any spilled oil immediately.
If the oil does not drain easily, change the tilt
angle or turn the outboard motor to port and
starboard to drain the oil.
10. Put a new gasket on the drain screw.
1. Bolt
1. Apron
1. Oil filler cap
1. Drain screw
2. Gasket
