Yamaha LS2000 Service Manual

1
GENERAL INFORMATION
1
GEN
INFO
SYMBOLS
Symbols 1 to 9 are designed as thumb-tabs
to indicate the content of a chapter:
General Information
Specifications
Periodic Inspection and Adjustment
Fuel System
Power Unit
Jet Pump Unit
Electrical System
Hull and Deck
Trouble Analysis
Symbols to indicate specific data:
Special Tool
Specified liquid
Specified engine speed
Specified torque
Specified measurement
Specified electrical valve
[Resistance (Ω), Voltage (V),
Electric current (A)]
Symbols to in an exploded diagram indi-
cate grade of lubricant and location of lubrica-
tion point:
Apply Yamaha 2-stroke outboard motor oil
Apply water resistant grease (Yamaha
grease A, Yamaha marine grease)
Apply molybdenum disulfide grease
Symbols to in an exploded diagram indi-
cate grade of sealing or locking agent, and
location of application point:
Apply Gasket Maker®
Apply Yamabond #4 (Yamaha bond No. 4)
Apply LOCTITE® No. 271 (Red LOCTITE)
Apply LOCTITE® No. 242 (Blue LOCTITE)
Apply LOCTITE® No. 567 (PST)
Apply Marine Grade Silicone sealant
NOTE: ______________________________
In this manual, the above symbols may not be
used in every case.
1
2
3
4
5
6
7
8
9
10
15
10
11
12
13
14
15
16
18
16
17
18
19
24
19
20
21
22
23
24
