Yamaha LS2000 Service Manual

7
HULL AND HOOD
ELECTRICAL
Item Unit LST1200
Free Play:
Throttle lever free play in (mm) 0.16 ~ 0.28” (4 ~ 7mm)
Choke cable free play in (mm) 0.04 ~ 0.24” (1 ~ 6mm)
Item Unit LST1200
Battery:
Type Marine group 24
Dual Purpose 675CCA
Capacity A•h (V/kC) 100 (12/68.4)
Ignition Timing:
Ignition timing (at 1200 rpm) degree 15 BTDC
Ignition timing (at 5500 rpm) degree 22 BTDC
Pulser Coil:
Test points Color code B-W/R, B-W/B, B-W/G
Resistance Ω 248 ~ 372
Peak voltage (open cranking) V 3.0 (min)
Peak voltage (closed cranking) V 2.0 (min)
Peak voltage (2000 RPM) V 11 (min)
Peak voltage (3500 RPM) V 20 (min)
Charge Coil 1:
Test points Color code Br-B/R
Resistance Ω 172 ~ 258
Peak voltage (open cranking) V 20 (min)
Peak voltage (closed cranking) V 20 (min)
Peak voltage (2000 RPM) V 45 (min)
Peak voltage (3500 RPM) V 65 (min)
Charge Coil 2:
Test points Color code L ~ B/R
Resistance Ω 656 ~ 984
Peak voltage (open cranking) V 90 (min)
Peak voltage (closed cranking) V 90 (min)
Peak voltage (2000 RPM) V 95 (min)
Peak voltage (3500 RPM) V 95 (min)
CDI Output:
Test points Color code B/O ~ B, B/W ~ B, B/Y ~ B
Peak voltage (closed cranking) V 95 (min)
Peak voltage (2000 RPM) V 100 (min)
Peak voltage (3500 RPM) V 100 (min)
