Yamaha LS2000 - Location of Main Components

Main Features:
1
Fuel Tank
2 Oil Tank
3 Blower Motor
4 Battery
Port/Starboard Features:
5 Flush Attachments
6 Fuel Filters
7 Electrical Boxes
8 Ignition Coil Holders
9 High Tension Cords
10 Spark Plugs
11 Silencer Covers
12 Hood Supports
13 Engine Compartment Vent Outlet
14 Engine Compartment Vent Inlets
15 Engine Compartment Drain Plug
16 Muffler Boxes
17 Fuel Tank Compartment Air Ventilation
18 Fuel Tank Compartment Drain Plu
g
FEATURES & FUNCTIONS 2
2-1
LOCATION OF MAIN COMPONENTS
1
3
4
55
6
7
7
8
8
9
9
10
10
11
11
12
2
12
13
14
15
16
16
17
17
18
