2-4
Control Features:
1 Speedometer
2 Tachometer
3 Low oil warning light
4 Steering wheel
5 Mirror
6 Switches and breakers
7 Fuel gauge
8 Ignition switch / keys
9 Chokes
2 F
EATURES & FUNCTIONS
LOCATION OF MAIN COMPONENTS
Control Features:
1 Bilge outlet
2 Clean-out compartment drain
3 Trailer strap eyes
4 Pump gates
5 Steering nozzles
6 Folding boarding step on transom
7 Hull drain plug
8 Speedometer pick-up
9 Deck drain
2
1
2
6
6
7
3
4
5
8
8
PORT
STARBOARD
STARBOARD
PORT
9
9
2
1
3
4
5
6
8
9
3
7
4
5
