Controls
&
CUE
Switches
These
adjust
the
overall
output
level
of
the
auxiliary
-
“mixes”
set
up
using
the
AUX
1,
AUX
2
and
AUX
3
con:
trols
on
the
input
channels,
AUX
SEND
1
sets
the
overall
level
of
the
AUX
1
mix
signal
appearing
at
the
AUX
SEND
1
jack,
AUX
SEND
2
sets
the
overall
level
of
the
AUX
2
mix
signal
appearing
at
the
AUX
SEND
2
jack,
and
AUX
SEND
3
sets
the
overall
level
of
the
AUX
3
mix
appearing
at
the
AUX
SEND
3
jack.
These
controls
should
be
used
to
optimally
match
the
AUX
SEND
out-
put
level
of
the
mixing
console
to
the
input
sensitivity
of
the
effect
unit,
signal
processing
device
or
amplifier
used.
The
CUE
switches
associated
with
each
AUX
SEND
con-
,
trol
can
be
used
to
send
the
corresponding
AUX
SEND
signal
to
the
PHONES
jack
via
the
CUE/PHONES
level
control.
The
AUX
cue
signal
will
be
added
to
any
other
active
cue
signal.
If
you
want
to
monitor
only
the
signal
from
a
single
AUX
buss,
make
sure
al!
other
CUE
switches
are
turned
OFF.
Ф
AUX
ВТМ
1
&
AUX
RTN
2
Controls
These
controls
adjust
the
level
of
the
signal
received
at
the
·
rear-panel
AUX
RTN
jacks
and
mixed
into
the
main
stereo
program.
Since.
stereo.
AUX
returns
are
provided
(AUX
RTN
1
L
&
R,
AUX
RTN
2
L
&
R)
the
AUX
RE-
TURN
controls
simultaneously
adjust
the
level
of
the.
signals
appearing
at
the
corresponding
|.
and
R
return
inputs,
The
returned
L
and
R
channel
signals
are
sent
to
the
L
and
R
stereo
buss
lines.
If
only
a
single-channel
signal
is
returned
(i.e.
a
plug
is
inserted
into
only
the
L
or
R
return
jack),
the
signal
wil!
be
fed
to
both
the
L
and
R
channels
of
the
stereo
buss.
