Yamaha MO6 - Normal Voice

Internal Structure (System Overview)
131
Owner’s Manual
Basic Structure
The following illustrations may help in understanding the memory structure of the Voices, Performances, and Mixings.
..................
..................
Preset 1
(128 Voices)
1 2 ...... 128
Preset 2
(128 Voices)
1 2 ...... 128
Preset 3
(128 Voices)
1 2 ...... 128
Preset Drum
(64 Voices)
1 2 ...... 64
GM Preset
(128 Voices)
1 2 ...... 128
GM Drum
(1 Voice)
1
User 1
(128 Voices)
1 2 ...... 128
User 2
(128 Voices)
1 2 ...... 128
Song 1
(16 Voices)
1 2 ...... 16
Song 64
(16 Voices)
1 2 ...... 16
Pattern 1
(16 Voices)
1 2 ...... 16
Pattern 64
(16 Voices)
1 2 ...... 16
User Drum
(32 Voices)
1 2 ...... 32
User 1
(128 Performances)
1 2 ...... 128
User 2
(128 Performances)
1 2 ...... 128
➞
..................
..................
Song 1
(16 Parts)
Pattern 1
(16 Parts)
Song 64
(16 Parts)
Te mplate
1
2
......
32
Pattern 64
(16 Parts)
➞
➞
PRE 1
A. PIANO
PRE 1
A. PIANO
PRE 2
KEYBOARD
PRE 3
ORGAN
USER 1
BASS
USER 1
BASS
USER 1
BASS
USER 2
STRINGS
USER 2
STRINGS
GM
BRASS
GM
BRASS
Preset 4
(128 Voices)
1 2 ...... 128
PRE 4
GUITAR
PLUCKED
FAVORITES
DRUM
KITS
FAVORITES
DRUM
KITS
FAVORITES
DRUM
KITS
VOICE
PERFORM
SONG
PATTERN
MIXING
MIXING
Normal Voice
Normal Voices: 512
Drum Voices: 64
Drum Voice
Voices
Preset Voice
Normal Voices: 128
Drum Voice: 1
GM Voice
Normal Voices: 256
Drum Voices: 32
User Voice
Normal Voices: up to 256
(Up to 16 Voices for each Song/
Pattern)
Mixing Voices
Performance
Mixing
n The Mixing Voices can be
selected only in the Song mode/
Pattern mode. These cannot be
selected in the Voice mode or
assigned to each Part in the
Performance mode.
