Yamaha MOTIF ES6 Data List

TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 20 14 (HEX)
TOTAL SIZE = 35 23 (HEX)
TOTAL SIZE = 68 44 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
30 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
:
04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
:
06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
:
08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
:
0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
:
0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
:
0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
:
10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
:
12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
:
14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
:
16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
:
18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
:
1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
:
1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
:
1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
:
20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
:
22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
23 1 01 – 7F Chorus Pan L63 – C – R63
24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127)
30 03 00 2 00 – 7F
00 – 7F
Insertion-A Type MSB
Insertion-A Type LSB
Refer to “Effect Parameter
List.”
for Analog Part
02 2 00 – 7F
00 – 7F
Insertion-A Parameter1 MSB
Insertion-A Parameter1 LSB
::
04 2 00 – 7F
00 – 7F
Insertion-A Parameter2 MSB
Insertion-A Parameter2 LSB
::
06 2 00 – 7F
00 – 7F
Insertion-A Parameter3 MSB
Insertion-A Parameter3 LSB
::
08 2 00 – 7F
00 – 7F
Insertion-A Parameter4 MSB
Insertion-A Parameter4 LSB
::
0A 2 00 – 7F
00 – 7F
Insertion-A Parameter5 MSB
Insertion-A Parameter5 LSB
::
0C 2 00 – 7F
00 – 7F
Insertion-A Parameter6 MSB
Insertion-A Parameter6 LSB
::
0E 2 00 – 7F
00 – 7F
Insertion-A Parameter7 MSB
Insertion-A Parameter7 LSB
::
10 2 00 – 7F
00 – 7F
Insertion-A Parameter8 MSB
Insertion-A Parameter8 LSB
::
12 2 00 – 7F
00 – 7F
Insertion-A Parameter9 MSB
Insertion-A Parameter9 LSB
::
14 2 00 – 7F
00 – 7F
Insertion-A Parameter10 MSB
Insertion-A Parameter10 LSB
::
16 2 00 – 7F
00 – 7F
Insertion-A Parameter11 MSB
Insertion-A Parameter11 LSB
::
18 2 00 – 7F
00 – 7F
Insertion-A Parameter12 MSB
Insertion-A Parameter12 LSB
::
1A 2 00 – 7F
00 – 7F
Insertion-A Parameter13 MSB
Insertion-A Parameter13 LSB
::
1C 2 00 – 7F
00 – 7F
Insertion-A Parameter14 MSB
Insertion-A Parameter14 LSB
::
1E 2 00 – 7F
00 – 7F
Insertion-A Parameter15 MSB
Insertion-A Parameter15 LSB
::
20 2 00 – 7F
00 – 7F
Insertion-A Parameter16 MSB
Insertion-A Parameter16 LSB
::
30 04 00 2 00 – 7F
00 – 7F
Insertion-B Type MSB
Insertion-B Type LSB
Refer to “Effect Parameter
List.”
for Analog Part
02 2 00 – 7F
00 – 7F
Insertion-B Parameter 1 MSB
Insertion-B Parameter 1 LSB
::
04 2 00 – 7F
00 – 7F
Insertion-B Parameter 2 MSB
Insertion-B Parameter 2 LSB
::
06 2 00 – 7F
00 – 7F
Insertion-B Parameter 3 MSB
Insertion-B Parameter 3 LSB
::
08 2 00 – 7F
00 – 7F
Insertion-B Parameter 4 MSB
Insertion-B Parameter 4 LSB
::
0A 2 00 – 7F
00 – 7F
Insertion-B Parameter 5 MSB
Insertion-B Parameter 5 LSB
::
0C 2 00 – 7F
00 – 7F
Insertion-B Parameter 6 MSB
Insertion-B Parameter 6 LSB
::
0E 2 00 – 7F
00 – 7F
Insertion-B Parameter 7 MSB
Insertion-B Parameter 7 LSB
::
10 2 00 – 7F
00 – 7F
Insertion-B Parameter 8 MSB
Insertion-B Parameter 8 LSB
::
12 2 00 – 7F
00 – 7F
Insertion-B Parameter 9 MSB
Insertion-B Parameter 9 LSB
::
14 2 00 – 7F
00 – 7F
Insertion-B Parameter 10 MSB
Insertion-B Parameter 10 LSB
::
16 2 00 – 7F
00 – 7F
Insertion-B Parameter 11 MSB
Insertion-B Parameter 11 LSB
::
18 2 00 – 7F
00 – 7F
Insertion-B Parameter 12 MSB
Insertion-B Parameter 12 LSB
::
1A 2 00 – 7F
00 – 7F
Insertion-B Parameter 13 MSB
Insertion-B Parameter 13 LSB
::
1C 2 00 – 7F
00 – 7F
Insertion-B Parameter 14 MSB
Insertion-B Parameter 14 LSB
::
1E 2 00 – 7F
00 – 7F
Insertion-B Parameter 15 MSB
Insertion-B Parameter 15 LSB
::
20 2 00 – 7F
00 – 7F
Insertion-B Parameter 16 MSB
Insertion-B Parameter 16 LSB
::
30 10 00 1 34 – 4C EQ Gain1 -12 – +12 [dB]
01 1 04 – 28 EQ Frequency1 32 – 2000 [Hz]
02 1 01 – 78 EQ Q1 0.1 – 12.0
03 1 00 – 01 EQ Shape1 shelv, peak
04 1 34 – 4C EQ Gain2 -12 – +12 [dB]
05 1 0E – 36 EQ Frequency2 100 – 10.0 [kHz]
06 1 01 – 78 EQ Q2 0.1 – 12.0
1 reserved
08 1 34 – 4C EQ Gain3 -12 – +12 [dB]
09 1 0E – 36 EQ Frequency3 100 – 10.0 [kHz]
0A 1 01 – 78 EQ Q3 0.1 – 12.0
1 Not Used
0C 1 34 – 4C EQ Gain4 -12 – +12 [dB]
0D 1 0E – 36 EQ Frequency4 100 – 10.0 [kHz]
0E 1 01 – 78 EQ Q4 0.1 – 12.0
1 Not Used
10 1 34 – 4C EQ Gain5 -12 – +12 [dB]
11 1 1C – 3A EQ Frequency5 0.5 – 16.0 [kHz]
12 1 01 – 78 EQ Q5 0.1 – 12.0
13 1 00 – 01 EQ Shape5 shelv, peak
30 11 00 2 00 – 7F
00 – 7F
Master Effect Type MSB
Master Effect Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Master Effect Parameter1 MSB
Master Effect Parameter1 LSB
:
04 2 00 – 7F
00 – 7F
Master Effect Parameter2 MSB
Master Effect Parameter2 LSB
:
06 2 00 – 7F
00 – 7F
Master Effect Parameter3 MSB
Master Effect Parameter3 LSB
:
08 2 00 – 7F
00 – 7F
Master Effect Parameter4 MSB
Master Effect Parameter4 LSB
:
0A 2 00 – 7F
00 – 7F
Master Effect Parameter5 MSB
Master Effect Parameter5 LSB
:
0C 2 00 – 7F
00 – 7F
Master Effect Parameter6 MSB
Master Effect Parameter6 LSB
:
0E 2 00 – 7F
00 – 7F
Master Effect Parameter7 MSB
Master Effect Parameter7 LSB
:
10 2 00 – 7F
00 – 7F
Master Effect Parameter8 MSB
Master Effect Parameter8 LSB
:
12 2 00 – 7F
00 – 7F
Master Effect Parameter9 MSB
Master EffectParameter9 LSB
:
14 2 00 – 7F
00 – 7F
Master Effect Parameter10 MSB
Master Effect Parameter10 LSB
:
16 2 00 – 7F
00 – 7F
Master Effect Parameter11 MSB
Master Effect Parameter11 LSB
:
18 2 00 – 7F
00 – 7F
Master Effect Parameter12 MSB
Master Effect Parameter12 LSB
:
1A 2 00 – 7F
00 – 7F
Master Effect Parameter13 MSB
Master Effect Parameter13 LSB
:
1C 2 00 – 7F
00 – 7F
Master Effect Parameter14 MSB
Master Effect Parameter14 LSB
:
1E 2 00 – 7F
00 – 7F
Master Effect Parameter15 MSB
Master Effect Parameter15 LSB
:
20 2 00 – 7F
00 – 7F
Master Effect Parameter16 MSB
Master Effect Parameter16 LSB
:
22 1 00 – 01 Master Effect ON/OFF 0: OFF, 1: ON
30 20 00 16 00 – 7F Plug-in Board Native System
Parameter
(for InsEF Plug-in)
30 20 10 48 00 – 7F Plug-in Board Native Parameter (for InsEF Plug-in)
30 20 40 3 00 – 7F
00 – 7F
00 – 7F
Plug-in Board Type MSB
Plug-in Board Type LSB
Plug-in Board Version Number
(for InsEF Plug-in)
43 1 00 – 7F reserved
72
Data List
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
