MIDI PARAMETER CHANGE TABLE (PERFORMANCE PART)
TOTAL SIZE = 58 3 (HEX)
pp = part number
00 – 03 Part 1 – 4 (Normal, Drum)
60 Part Plug-in 1 (User, Preset, Direct)
61 Part Plug-in 2 (User, Preset, Direct)
62 Part Plug-in 3 (User, Preset, Direct)
Address Size Data Range
(HEX)
Parameter Name Description Notes
31 pp 00 1 00 – 7F Bank Select MSB 0 – 127
01 1 00 – 7F Bank Select LSB 0 – 127
02 1 00 – 7F Program Number 1 – 128
03 1 reserved
04 1 00 – 01 Part Mode mono, poly
05 1 01 – 7F Velocity Limit Low 1 – 127
06 1 01 – 7F Velocity Limit High 1 – 127
07 1 00 – 7F Note Limit Low C-2 – G8
08 1 00 – 7F Note Limit High C-2 – G8
09 1 10 – 58 Pitch Bend Range Upper -48 – +24 (PB Part: -24 – +24)
0A 1 10 – 58 Pitch Bend Range Lower -48 – +24
0B 1 00 – 7F Velocity Sense Depth 0 – 127
0C 1 00 – 7F Velocity Send Offset 0 – 127
0D 1 00 – 7F Volume 0 – 127
0E 1 01 – 7F Pan L63 – C – R63
0F 1 reserved
10 2 00 – 0F
00 – 0F
Detune MSB
Detune LSB
-12.8 – +12.7 [Hz]
1st bit3-0 → bit7-4
2nd bit3-0 → bit3-0
12 1 00 – 7F Reverb Send 0 – 127
13 1 00 – 7F Chorus Send 0 – 127
14 1 00 – 7F reserved
15 1 00 – 7F Dry Level 0 – 127
16 1 28 – 58 Note Shift -24 – +24 [semitones]
17 1 00 – 7F Filter Cutoff Frequency -64 – +63
18 1 00 – 7F Filter Resonance/Width -64 – +63
19 1 reserved
1A 1 00 – 01 Portamento Switch off, on
1B 1 00 – 7F Portamento Time 0 – 127
1C 1 00 – 01 Portamento Mode fingered, fulltime
1D 1 reserved
1E 1 00 – 7F Output Select 0: L&R, 8: asnL&R, 9-15: asn1&2 – asn13&14
64 – 79: asnL, asnR, asn1 – asn14,
127: drum (or L&R)
31 pp 1F 1 00 – 7F Layer Sw
Arpeggio Sw
Receive Control Change
Receive AT
Receive PB
bit0: Layer Sw off, on
bit1: Arpeggio Sw off, on
bit2: off, on Control Change
bit3: reserved
bit4: reserved
bit5: off, on AT
bit6: off, on PB
Part1: on, Other: off
Part1: on, Other: off
20 1 00 – 7F Receive Volume/Expression
Receive Sustain/Sostenuto
Receive MW
bit0: off, on Expression
bit1: reserved
bit2: reserved
bit3: off, on Sustain/Sostenuto
bit4: reserved
bit5: off, on MW
bit6: reserved
21 1 00 – 7F Receive FC2
Receive FS
Receive FC1
Receive BC
Receive Knob1
Receive Knob2
Receive RB
bit0: off, on FC2
bit1: off, on FS
bit2: off, on FC1
bit3: off, on BC
bit4: off, on KN1
bit5: off, on KN2
bit6: off, on RB
31 pp 22 1 00 – 7F AEG Decay2 Level (EG Sustain Level) -64 – +63
23 1 00 – 7F AEG Attack Time (EG Attack Time) -64 – +63
24 1 00 – 01 Voice Pan on/off off, on
25 1 00 – 7F AEG Decay2 Time (EG Decay Time) -64 – +63
26 1 00 – 7F AEG Release Time (EG Release Time) -64 – +63
27 1 00 – 7F FEG Decay2 Level (EG Sustain Level) -64 – +63
28 1 00 – 7F FEG Attack Time (EG Attack Time) -64 – +63
29 1 reserved
2A 1 00 – 7F FEG Decay2 Time (EG Decay Time) -64 – +63
2B 1 00 – 7F FEG Release Time (EG Release Time) -64 – +63
2C 1 00 – 7F FEG DEPTH -64 – +63
31 pp 2D 1 00 reserved
2E 2 002E – 00B6 Low Frequency MSB
Low Frequency LSB
50.1 – 2.00k
30 1 20 – 60 Low Gain -32 – +32
31 1 00 reserved
32 2 0053 – 00F1 Mid Frequency MSB
Mid Frequency LSB
139.7 – 10.1k
34 1 20 – 60 Mid Gain -32 – +32
35 1 00 – 1F Mid Resonance 0 – 31
36 2 0083 – 00FF High Frequency MSB
High Frequency LSB
503.8 – 14k
38 1 20 – 60 High Gain -32 – +32
39 1 00 reserved
Data List
73
MIDI Data Table
