Yamaha MOTIF ES6 Data List

TOTAL SIZE = 8 08 (HEX)
pp = part number
40 – 44 AD Part
MIDI PARAMETER CHANGE TABLE (NORMAL VOICE COMMON)
Address Size Data Range
(HEX)
Parameter Name Description Notes
34 pp 00 1 00 – 03 A/D Input Mode L mono, R mono, L+R mono, stereo
01 1 00 – 7F A/D Part Volume 0 – 127
02 1 01 – 7F A/D Part Pan L63 – C – R63
03 1 00 – 7F A/D Part Reverb Send 0 – 127
04 1 00 – 7F A/D Part Chorus Send 0 – 127
05 1 00 – 7F reserved
06 1 00 – 7F A/D Part Dry Level 0 – 127
07 1 00 – 4F A/D Part Output Select 0: L&R
8: asnL&R
9-15: asn1&2 – asn13&14
64 – 79: asnL, asnR, asn1 – asn14
TOTAL SIZE = 82 52 (HEX)
TOTAL SIZE = 17 11 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
40 70 00 1 20 – 7E Voice Name1 32 – 126 (ASCII)
01 1 20 – 7E Voice Name2 32 – 126 (ASCII)
02 1 20 – 7E Voice Name3 32 – 126 (ASCII)
03 1 20 – 7E Voice Name4 32 – 126 (ASCII)
04 1 20 – 7E Voice Name5 32 – 126 (ASCII)
05 1 20 – 7E Voice Name6 32 – 126 (ASCII)
06 1 20 – 7E Voice Name7 32 – 126 (ASCII)
07 1 20 – 7E Voice Name8 32 – 126 (ASCII)
08 1 20 – 7E Voice Name9 32 – 126 (ASCII)
09 1 20 – 7E Voice Name10 32 – 126 (ASCII)
0A 1 reserved
0B 1 reserved
0C 1 00 – 10 Voice Category (Main) 0 – 16 (-- – Co) Ap, Kb, Or, Gt,
Ba, St, Br, Rp,
Ld, Pd, Sc, Cp,
Dr, Se, Me, Co
0D 1 00 – 03 Voice Category (Sub) 0 – 3 (-- – Sub1 – Sub3) Refer to
“Category List.”
0E 1 reserved
0F 1 reserved
10 1 reserved
11 1 reserved
12 1 reserved
40 70 13 1 reserved
14 2 0000 –
20FF
ARP Type MSB
ARP Type LSB
0 – 1786: Preset,
8192-8447: User
16 1 00 – 01 ARP Switch off, on
17 1 00 – 02 ARP Hold sync-off, off, on
18 1 00 – 06 ARP Unit Multiplay 50%, 66%, 75%, 100%,
133%, 150%, 200%
19 1 00 – 7F ARP Note Limit Low C-2 – G8
1A 1 00 – 7F ARP Note Limit High C-2 – G8
1B 1 01 – 7F ARP Velocity Limit Low 1 – 127
1C 1 01 – 7F ARP Velocity Limit High 1 – 127
1D 1 00 – 04 ARP Key Mode sort, thru, direct,
sort+direct, thru+direct
1E 1 00 – 01 ARP Vel Mode original, thru
1F 1 00 – 01 ARP Change Timing realtime, measure
20 1 00 – 06 ARP Quantize Value 32th,16th Triplet, 16th, 8th
Triplet, 8th, 4th Triplet, 4th
21 1 00 – 64 ARP Quantize Strength 0 – 100%
22 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200%
24 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate Time Rate LSB
0 – 200%
26 2 0008 –
00F8
ARP Swing MSB
ARP Swing LSB
-120 – 0 – +120
28 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300
2A 2 0000 –
3FFF
ARP SF1 Assign Type MSB
ARP SF1 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
2C 2 0000 –
3FFF
ARP SF2 Assign Type MSB
ARP SF2 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
2E 2 0000 –
3FFF
ARP SF3 Assign Type MSB
ARP SF3 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
30 2 0000 –
3FFF
ARP SF4 Assign Type MSB
ARP SF4 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
32 2 0000 –
3FFF
ARP SF5 Assign Type MSB
ARP SF5 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
40 70 34 1 00 – 05 Knob Function Select 0=Pan&Send, 1=Tone,
2=Assign, 3=MeqOffset,
4=MasterEffect, 5=ARP FX
35 1 01 – 7F Pan L63 – C – R63
36 1 40 reserved
37 1 00 – 7F QED Decay Time -64 – +63
38 1 00 – 7F QED Sustain Level -64 – +63
39 1 00 – 7F QED FEG Attack Time -64 – +63
3A 1 00 – 7F QED FEG Decay Time -64 – +63
3B 1 00 – 7F QED FEG Release Time -64 – +63
3C 1 reserved
3D 1 00 – 7F QED FEG Depth -64 – +63
3E 1 00 – 7F KnobA -64 – +63
3F 1 00 – 7F KnobB -64 – +63
40 1 reserved
41 1 00 – 7F EQ Low Gain -64 – +63
42 1 00 – 7F EQ Low Mid Gain -64 – +63
43 1 00 – 7F EQ High Mid Gain -64 – +63
44 1 00 – 7F EQ High Gain -64 – +63
45 1 00 – 7F Assign1 -64 – +63
46 1 00 – 7F Assign2 -64 – +63
47 1 00 – 7F Cutoff Frequency -64 – +63
48 1 00 – 7F Resonance -64 – +63
49 1 00 – 7F Attack Time -64 – +63
4A 1 00 – 7F Release Time -64 – +63
4B 1 reserved
4C 1 reserved
4D 1 reserved
4E 1 reserved
4F 1 reserved
50 1 reserved
51 1 reserved
40 00 00 1 00 – 7F reserved
01 1 00 – 7F Volume 0 – 127
02 1 00 – 01 Same Note Number Key On
Assign
single, multi
03 1 00 – 01 QED Mono/Poly Mode mono, poly
04 1 00 – 0C Micro Tuning Scale Equal, PureMajor, PureMinor,
Werckmeist, Kirnberger,
Vallot&Yng, 1/4 Shift,
1/4 Tone, 1/8 Tone, Indian,
Arabic 1, Arabic 2, Arabic 3
05 1 10 – 58 QED Pitch Bend Range Upper -48 – +24 [semitones]
06 1 10 – 58 QED Pitch Bend Range Lower -48 – +24 [semitones]
07 1 00 – 01 QED Portamento Mode fingered, fulltime
08 1 00 – 01 QED Portamento Switch off, on
09 1 00 – 7F QED Portamento Time 0 – 127
0A 1 00 – 03 Portamento Time Mode rate1, time1, rate2, time2
0B 1 00 – 7F Reverb Send -∞dB – 0dB
0C 1 00 – 7F Chorus Send -∞dB – 0dB
0D 1 reserved
0E 1 reserved
0F 1 00 – 0B Micro Tuning Root C – B
10 1 00 – 07 Legato Slope 0 – 7
Address Size Data
Range
(HEX)
Parameter Name Description Notes
74
Data List
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
