Yamaha MOTIF ES6 Data List

MIDI PARAMETER CHANGE TABLE (DRUM VOICE COMMON)
TOTAL SIZE = 82 52 (HEX)
TOTAL SIZE = 8 08 (HEX)
TOTAL SIZE = 4 04 (HEX)
TOTAL SIZE = 36 24 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
46 70 00 1 20 – 7E Voice Name1 32 – 126 (ASCII)
01 1 20 – 7E Voice Name2 32 – 126 (ASCII)
02 1 20 – 7E Voice Name3 32 – 126 (ASCII)
03 1 20 – 7E Voice Name4 32 – 126 (ASCII)
04 1 20 – 7E Voice Name5 32 – 126 (ASCII)
05 1 20 – 7E Voice Name6 32 – 126 (ASCII)
06 1 20 – 7E Voice Name7 32 – 126 (ASCII)
07 1 20 – 7E Voice Name8 32 – 126 (ASCII)
08 1 20 – 7E Voice Name9 32 – 126 (ASCII)
09 1 20 – 7E Voice Name10 32 – 126 (ASCII)
0A 1 reserved
0B 1 reserved
0C 1 00 – 10 Voice Category (Main) 0 – 16 (-- – Co) Ap, Kb, Or, Gt,
Ba, St, Br, Rp,
Ld, Pd, Sc, Cp,
Dr, Se, Me, Co
0D 1 00 – 03 Voice Category (Sub) 0 – 3 (-- – Sub1 – Sub3) Depends on
Main Category.
0E 1 reserved
0F 1 reserved
10 1 reserved
11 1 reserved
12 1 reserved
46 70 13 1 reserved
14 2 0000 –
20FF
ARP Type MSB
ARP Type LSB
0 – 1786: Preset,
8192 – 8447: User
16 1 00 – 01 ARP Switch off, on
17 1 00 – 02 ARP Hold sync-off, off, on
18 1 00 – 06 ARP Unit Multiplay 50%, 66%, 75%, 100%,
133%, 150%, 200%
19 1 00 – 7F ARP Note Limit Low C-2 – G8
1A 1 00 – 7F ARP Note Limit High C-2 – G8
1B 1 01 – 7F ARP Velocity Limit Low 1 – 127
1C 1 01 – 7F ARP Velocity Limit High 1 – 127
1D 1 00 – 04 ARP Key Mode sort, thru, direct,
sort+direct, thru+direct
1E 1 00 – 01 ARP Vel Mode original, thru
1F 1 00 – 01 ARP Change Timing realtime, measure
20 1 00-06 ARP Quantize Value 32th,16th Triplet, 16th, 8th
Triplet, 8th, 4th Triplet, 4th
21 1 00-64 ARP Quantize Strength 0 – 100%
22 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200%
24 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate Time Rate LSB
0 – 200%
26 2 0008 –
00F8
ARP Swing MSB
ARP Swing LSB
-120 – 0 – +120
28 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300
2A 2 0008 –
00F8
ARP SF1 Assign Type MSB
ARP SF1 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
2C 2 0008 –
00F8
ARP SF2 Assign Type MSB
ARP SF2 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
2E 2 0008 –
00F8
ARP SF3 Assign Type MSB
ARP SF3 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
30 2 00 – 7F
00 – 7F
ARP SF4 Assign Type MSB
ARP SF4 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
32 2 00 – 7F
00 – 7F
ARP SF5 Assign Type MSB
ARP SF5 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
46 70 34 1 00 – 05 Knob Function Select 0=Pan&Send, 1=Tone,
2=Assign, 3=MeqOffset,
4=MasterEffect,
5=ARP FX
35 1 01 – 7F Pan L63 – C – R63
36 1 reserved
37 1 00 – 7F QED Decay Time -64 – +63
38 1 reserved
39 1 reserved
3A 1 reserved
3B 1 reserved
3C 1 reserved
3D 1 reserved
3E 1 00 – 7F KnobA -64 – +63
3F 1 00 – 7F KnobB -64 – +63
40 1 reserved
41 1 00 – 7F EQ Low Gain -64 – +63
42 1 00 – 7F EQ Low Mid Gain -64 – +63
43 1 00 – 7F EQ High Mid Gain -64 – +63
44 1 00 – 7F EQ High Gain -64 – +63
45 1 00 – 7F Assign1 -64 – +63
46 1 00 – 7F Assign2 -64 – +63
47 1 00 – 7F Cutoff Frequency -64 – +63
48 1 00 – 7F Resonance -64 – +63
49 1 00 – 7F Attack Time -64 – +63
4A 1 reserved
4B 1 reserved
4C 1 reserved
4D 1 reserved
4E 1 reserved
4F 1 reserved
50 1 reserved
51 1 reserved
46 00 00 1 00 – 7F Volume 0 – 127
01 1 reserved
02 1 10 – 58 QED Pitch Bend Range Upper -48 – +24 [semitones]
03 1 10 – 58 QED Pitch Bend Range Lower -48 – +24 [semitones]
04 1 00 – 7F Reverb Send -∞dB – 0dB
05 1 00 – 7F Chorus Send -∞dB – 0dB
06 1 reserved
07 1 reserved
46 00 40 1 00 – 02 Insertion Connect Type Para, A->B, B->A
41 1 00 – 7F Ins-EF Reverb Send Level 0 – 127
42 1 00 – 7F Ins-EF Chorus Send Level 0 – 127
43 1 reserved
46 01 00 2 00 – 7F
00 – 7F
Reverb Type MSB
Reverb Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
:
04 2 00 – 7F
00 – 7F
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
:
06 2 00 – 7F
00 – 7F
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
:
08 2 00 – 7F
00 – 7F
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
:
0A 2 00 – 7F
00 – 7F
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
:
0C 2 00 – 7F
00 – 7F
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
:
0E 2 00 – 7F
00 – 7F
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
:
10 2 00 – 7F
00 – 7F
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
:
12 2 00 – 7F
00 – 7F
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
:
14 2 00 – 7F
00 – 7F
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
:
16 2 00 – 7F
00 – 7F
Reverb Parameter 11 MSB
Reverb Parameter 11 LSB
:
18 2 00 – 7F
00 – 7F
Reverb Parameter 12 MSB
Reverb Parameter 12 LSB
:
1A 2 00 – 7F
00 – 7F
Reverb Parameter 13 MSB
Reverb Parameter 13 LSB
:
1C 2 00 – 7F
00 – 7F
Reverb Parameter 14 MSB
Reverb Parameter 14 LSB
:
1E 2 00 – 7F
00 – 7F
Reverb Parameter 15 MSB
Reverb Parameter 15 LSB
:
20 2 00 – 7F
00 – 7F
Reverb Parameter 16 MSB
Reverb Parameter 16 LSB
:
22 1 00 – 7F Reverb Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
23 1 01 – 7F Reverb Pan L63 – C – R63
Address Size Data
Range
(HEX)
Parameter Name Description Notes
78
Data List
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
