Yamaha MOTIF ES6 Data List

TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 30 1E (HEX)
MIDI PARAMETER CHANGE TABLE (DRUM VOICE KEY)
TOTAL SIZE = 19 13 (HEX)
TOTAL SIZE = 12 0C (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
46 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
:
04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
:
06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
:
08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
:
0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
:
0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
:
0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
:
10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
:
12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
:
14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
:
16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
:
18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
:
1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
:
1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
:
1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
:
20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
:
22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
23 1 01 – 7F Chorus Pan L63 – C – R63
24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127)
46 03 00 2 00 – 7F
00 – 7F
Insertion-A Type MSB
Insertion-A Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Insertion-A Parameter1 MSB
Insertion-A Parameter1 LSB
:
04 2 00 – 7F
00 – 7F
Insertion-A Parameter2 MSB
Insertion-A Parameter2 LSB
:
06 2 00 – 7F
00 – 7F
Insertion-A Parameter3 MSB
Insertion-A Parameter3 LSB
:
08 2 00 – 7F
00 – 7F
Insertion-A Parameter4 MSB
Insertion-A Parameter4 LSB
:
0A 2 00 – 7F
00 – 7F
Insertion-A Parameter5 MSB
Insertion-A Parameter5 LSB
:
0C 2 00 – 7F
00 – 7F
Insertion-A Parameter6 MSB
Insertion-A Parameter6 LSB
:
0E 2 00 – 7F
00 – 7F
Insertion-A Parameter7 MSB
Insertion-A Parameter7 LSB
:
10 2 00 – 7F
00 – 7F
Insertion-A Parameter8 MSB
Insertion-A Parameter8 LSB
:
12 2 00 – 7F
00 – 7F
Insertion-A Parameter9 MSB
Insertion-A Parameter9 LSB
:
14 2 00 – 7F
00 – 7F
Insertion-A Parameter10 MSB
Insertion-A Parameter10 LSB
:
16 2 00 – 7F
00 – 7F
Insertion-A Parameter11 MSB
Insertion-A Parameter11 LSB
:
18 2 00 – 7F
00 – 7F
Insertion-A Parameter12 MSB
Insertion-A Parameter12 LSB
:
1A 2 00 – 7F
00 – 7F
Insertion-A Parameter13 MSB
Insertion-A Parameter13 LSB
:
1C 2 00 – 7F
00 – 7F
Insertion-A Parameter14 MSB
Insertion-A Parameter14 LSB
:
1E 2 00 – 7F
00 – 7F
Insertion-A Parameter15 MSB
Insertion-A Parameter15 LSB
:
20 2 00 – 7F
00 – 7F
Insertion-A Parameter16 MSB
Insertion-A Parameter16 LSB
:
46 05 00 1 00 – 0C Controller Set1 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
01 2 00
00 – 23
Controller Set1 Destination MSB
Controller Set1 Destination LSB
0 – 35
03 1 00 – 7F Controller Set1 Depth -64 – +63
04 1 reserved
05 1 00 – 0C Controller Set2 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
06 2 00
00 – 23
Controller Set2 Destination MSB
Controller Set2 Destination LSB
0 – 35
08 1 00 – 7F Controller Set2 Depth -64 – +63
09 1 reserved
0A 1 00 – 0C Controller Set3 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
0B 2 00
00 – 23
Controller Set3 Destination MSB
Controller Set3 Destination LSB
0 – 35
0D 1 00 – 7F Controller Set3 Depth -64 – +63
0E 1 reserved
0F 1 00 – 0C Controller Set4 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
10 2 00
00 – 23
Controller Set4 Destination MSB
Controller Set4 Destination LSB
0 – 35
12 1 00 – 7F Controller Set4 Depth -64 – +63
13 1 reserved
14 1 00 – 0C Controller Set5 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
15 2 00
00 – 23
Controller Set5 Destination MSB
Controller Set5 Destination LSB
0 – 35
17 1 00 – 7F Controller Set5 Depth -64 – +63
18 1 reserved
19 1 00 – 0C Controller Set6 Source 0: PB, 1: MW, 3: AT, 4: FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
1A 2 00
00 – 23
Controller Set6 Destination MSB
Controller Set6 Destination LSB
0 – 35
1C 1 00 – 7F Controller Set6 Depth -64 – +63
1D 1 reserved
Address Size Data
Range
(HEX)
Parameter Name Description Notes
47 ee 00 1 00 – 01 Element Assign off, on
01 1 00 – 02 Wave Type 0: PresetWave,
1: Voice,
2: UserWave,
02 1 reserved
03 1 00 – 01 Receive Note Off off, on
04 1 00 – 01 Assign Mode single, multi *1
05 1 00 – 7F Alternate Group 0: off, 1 – 127
06 2 00 – 7F
00 – 7F
Wave Number MSB
Wave Number LSB
1st bit6-0 → bit13-7
(User: 1 - 1024)
2nd bit6-0 → bit6-0
08 3 00 – 7F
00 – 7F
00 – 7F
Voice Bank Number MSB
Voice Bank Number LSB
Voice Number
0 – 127
0 – 127
0 – 127
*1
*1
*1
0B 1 01 – 7F Pan L63 – C – R63 *1
0C 1 00 – 7F Random Pan Depth 0 – 127
0D 1 00 – 7F Alternate Pan Depth L64 – 0 – R63
0E 1 00 – 7F Reverb Send Level 0 – 127 *1
0F 1 00 – 7F Chorus Send Level 0 – 127 *1
10 1 reserved
11 1 00 – 02 Insertion Effect Switch thru, insA, insB *1
12 1 00 – 4F Output Select 0: L&R
8: asnL&R
9 – 15: asn1&2 – asn13&14
64 – 79: asnL, asnR,
asn1 – asn14
*1
47 ee 20 1 00 – 7F Element Level 0 – 127 *1
21 1 00 – 7F Level Velocity Sensitivity -64 – +63
22 1 reserved
23 1 00 – 7F AEG Attack Time 0 – 127
24 1 00 – 7F AEG Decay1 Time 0 – 127
25 1 00 – 7F AEG Decay2 Time 0 – 126, hold
26 1 reserved
27 1 reserved
28 1 reserved
29 1 00 – 7F AEG Decay1 Level 0 – 127
2A 1 reserved
2B 1 reserved
Data List
79
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
