TOTAL SIZE = 3 03 (HEX)
TOTAL SIZE = 8 08 (HEX)
TOTAL SIZE = 8 08 (HEX)
ee = Element Number (00 – 48: C0 – C6)
*1 When the Wave/Voice type is set to “voice,” only these parameters are available.
MIDI PARAMETER CHANGE TABLE (PLUG-IN VOICE)
* Receives the Plug-in Voice Parameter Change of the CS6x (ID=0x64) and complies with the Parameter Request.
TOTAL SIZE = 82 52 (HEX)
TOTAL SIZE = 13 0D (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
48 ee 00 1 10 – 70 Coarse Tune -48 – +48 *1
01 1 00 – 7F Fine Tune -64 – +63 *1
02 1 00 – 7F Pitch Velocity Sensitivity -64 – +63
49 ee 00 1 reserved
01 2 00 – 01
00 – 7F
LPF Cutoff Frequency MSB
LPF Cutoff Frequency LSB
0 – 255
03 1 00 – 7F LPF Cutoff Velocity Sensitivity -64 – +63
04 1 00 – 7F LPF Resonance 0 – 127
05 1 reserved
06 2 00 – 01
00 – 7F
HPF Cutoff Frequency MSB
HPF Cutoff Frequency LSB
0 – 255
4A ee 00 1 00 – 05 EQ Type EQ L/H, P.EQ, Boost6,
Boost12, Boost18, thru
01 1 00 – 1F EQ Resonance 0 – 31
02 2 00 – 01
00 – 7F
EQ 1 Frequency MSB
EQ 1 Frequency LSB
EQ L/H: 46-182, P.EQ: 83-251
04 1 20 – 60 EQ 1 GAIN -32 – +32
05 2 00 – 01
00 – 7F
EQ 2 Frequency MSB
EQ 2 Frequency LSB
EQ L/H: 131-241
07 1 20 – 60 EQ 2 GAIN -32 – +32
Address Size Data
Range
(HEX)
Parameter Name Description Notes
4C 70 00 1 20 – 7E Voice Name1 32 – 126 (ASCII)
01 1 20 – 7E Voice Name2 32 – 126 (ASCII)
02 1 20 – 7E Voice Name3 32 – 126 (ASCII)
03 1 20 – 7E Voice Name4 32 – 126 (ASCII)
04 1 20 – 7E Voice Name5 32 – 126 (ASCII)
05 1 20 – 7E Voice Name6 32 – 126 (ASCII)
06 1 20 – 7E Voice Name7 32 – 126 (ASCII)
07 1 20 – 7E Voice Name8 32 – 126 (ASCII)
08 1 20 – 7E Voice Name9 32 – 126 (ASCII)
09 1 20 – 7E Voice Name10 32 – 126 (ASCII)
0A 1 reserved
0B 1 reserved
0C 1 00 – 10 Voice Category (Main) 0 – 16 (-- – Co) Ap, Kb, Or, Gt,
Ba, St, Br, Rp,
Ld, Pd, Sc,
Cp, Dr, Se,
Me, Co
0D 1 00 – 03 Voice Category (Sub) 0 – 3 (-- – Sub1 – Sub3)
Depends on
Main Category.
0E 1 reserved
0F 1 reserved
10 1 reserved
11 1 reserved
12 1 reserved
4C 70 13 1 reserved
14 2 0000 –
20FF
ARP Type MSB
ARP Type LSB
0 – 1786: Preset,
8192-8447: User
16 1 00 – 01 ARP Switch off, on
17 1 00 – 02 ARP Hold sync-off, off, on
18 1 00 – 06 ARP Unit Multiply 50%, 66%, 75%, 100%,
133%, 150%, 200%
19 1 00 – 7F ARP Note Limit Low C-2 – G8
1A 1 00 – 7F ARP Note Limit High C-2 – G8
1B 1 01 – 7F ARP Velocity Limit Low 1 – 127
1C 1 01 – 7F ARP Velocity Limit High 1 – 127
1D 1 00 – 04 ARP Key Mode sort, thru, direct, sort+direct,
thru+direct
1E 1 00 – 01 ARP Vel Mode original, thru
1F 1 00 – 01 ARP Change Timing realtime, measure
20 1 00-06 ARP Quantize Value 32th, 16th Triplet,16th,
8th Triplet, 8th, 4th Triplet, 4th
21 1 00-64 ARP Quantize Strength 0–100%
22 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0–200%
24 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate Time Rate LSB
0–200%
26 2 0000 –
3FFF
ARP Swing MSB
ARP Swing LSB
-120–0–+120
28 2 0001 –
012C
ARP Tempo MSB
ARP Tempo LSB
1 – 300
2A 2 0000 –
3FFF
ARP SF1 Assign Type MSB
ARP SF1 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
2C 2 0000 –
3FFF
ARP SF2 Assign Type MSB
ARP SF2 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
2E 2 0000 –
3FFF
ARP SF3 Assign Type MSB
ARP SF3 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
30 2 0000 –
3FFF
ARP SF4 Assign Type MSB
ARP SF4 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
32 2 0000 –
3FFF
ARP SF5 Assign Type MSB
ARP SF5 Assign Type LSB
0 – 1786: Preset,
8192-8447: User,
16383: No Type
4C 70 34 1 00 – 05 Knob Function Select 0=Pan&Send, 1=Tone,
2=Assign, 3=MeqOffset,
4=MasterEffect, 5=ARP FX
35 1 01 – 7F Pan L63 – C – R63
36 1 reserved
37 1 00 – 7F QED Decay Time -64 – +63
38 1 reserved
39 1 reserved
3A 1 reserved
3B 1 reserved
3C 1 reserved
3D 1 reserved
3E 1 00 – 7F KnobA -64 – +63
3F 1 00 – 7F KnobB -64 – +63
40 1 reserved
41 1 00 – 7F EQ Low Gain -64 – +63
42 1 00 – 7F EQ Low Mid Gain -64 – +63
43 1 00 – 7F EQ High Mid Gain -64 – +63
44 1 00 – 7F EQ High Gain -64 – +63
45 1 00 – 7F Assign1 -64 – +63
46 1 00 – 7F Assign2 -64 – +63
47 1 00 – 7F Cutoff Frequency -64 – +63
48 1 00 – 7F Resonance -64 – +63
49 1 00 – 7F Attack Time -64 – +63
4A 1 00 – 7F Release Time -64 – +63
4B 1 reserved
4C 1 reserved
4D 1 reserved
4E 1 reserved
4F 1 reserved
50 1 reserved
51 1 reserved
4C 00 00 1 00 – 7F Volume 0 – 127
01 1 reserved
02 1 00 – 01 Same Note Number Key On
Assign
single, multi
03 1 00 – 01 QED Mono/Poly Mode mono, poly
04 1 reserved
05 1 28 – 58 QED Pitch Bend Range -24 – +24 [semitones]
06 1 reserved
07 1 reserved
08 1 00 – 01 QED Portamento Switch off, on
09 1 00 – 7F QED Portamento Time 0 – 127
0A 1 01 – 02 Insertion Connect Type A->B, B->A
0B 1 00 – 7F Reverb Send -∞dB – 0dB
0C 1 00 – 7F Chorus Send -∞dB – 0dB
Address Size Data
Range
(HEX)
Parameter Name Description Notes
