Yamaha MOTIF ES6 Data List

TOTAL SIZE = 36 24 (HEX)
TOTAL SIZE = 37 25 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 34 22 (HEX)
TOTAL SIZE = 10 0A (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
4C 01 00 2 00 – 7F
00 – 7F
Reverb Type MSB
Reverb Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Reverb Parameter 1 MSB
Reverb Parameter 1 LSB
:
04 2 00 – 7F
00 – 7F
Reverb Parameter 2 MSB
Reverb Parameter 2 LSB
:
06 2 00 – 7F
00 – 7F
Reverb Parameter 3 MSB
Reverb Parameter 3 LSB
:
08 2 00 – 7F
00 – 7F
Reverb Parameter 4 MSB
Reverb Parameter 4 LSB
:
0A 2 00 – 7F
00 – 7F
Reverb Parameter 5 MSB
Reverb Parameter 5 LSB
:
0C 2 00 – 7F
00 – 7F
Reverb Parameter 6 MSB
Reverb Parameter 6 LSB
:
0E 2 00 – 7F
00 – 7F
Reverb Parameter 7 MSB
Reverb Parameter 7 LSB
:
10 2 00 – 7F
00 – 7F
Reverb Parameter 8 MSB
Reverb Parameter 8 LSB
:
12 2 00 – 7F
00 – 7F
Reverb Parameter 9 MSB
Reverb Parameter 9 LSB
:
14 2 00 – 7F
00 – 7F
Reverb Parameter 10 MSB
Reverb Parameter 10 LSB
:
16 2 00 – 7F
00 – 7F
Reverb Parameter 11 MSB
Reverb Parameter 11 LSB
:
18 2 00 – 7F
00 – 7F
Reverb Parameter 12 MSB
Reverb Parameter 12 LSB
:
1A 2 00 – 7F
00 – 7F
Reverb Parameter 13 MSB
Reverb Parameter 13 LSB
:
1C 2 00 – 7F
00 – 7F
Reverb Parameter 14 MSB
Reverb Parameter 14 LSB
:
1E 2 00 – 7F
00 – 7F
Reverb Parameter 15 MSB
Reverb Parameter 15 LSB
:
20 2 00 – 7F
00 – 7F
Reverb Parameter 16 MSB
Reverb Parameter 16 LSB
:
22 1 00 – 7F Reverb Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
23 1 01 – 7F Reverb Pan L63 – C – R63
4C 02 00 2 00 – 7F
00 – 7F
Chorus Type MSB
Chorus Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Chorus Parameter 1 MSB
Chorus Parameter 1 LSB
:
04 2 00 – 7F
00 – 7F
Chorus Parameter 2 MSB
Chorus Parameter 2 LSB
:
06 2 00 – 7F
00 – 7F
Chorus Parameter 3 MSB
Chorus Parameter 3 LSB
:
08 2 00 – 7F
00 – 7F
Chorus Parameter 4 MSB
Chorus Parameter 4 LSB
:
0A 2 00 – 7F
00 – 7F
Chorus Parameter 5 MSB
Chorus Parameter 5 LSB
:
0C 2 00 – 7F
00 – 7F
Chorus Parameter 6 MSB
Chorus Parameter 6 LSB
:
0E 2 00 – 7F
00 – 7F
Chorus Parameter 7 MSB
Chorus Parameter 7 LSB
:
10 2 00 – 7F
00 – 7F
Chorus Parameter 8 MSB
Chorus Parameter 8 LSB
:
12 2 00 – 7F
00 – 7F
Chorus Parameter 9 MSB
Chorus Parameter 9 LSB
:
14 2 00 – 7F
00 – 7F
Chorus Parameter 10 MSB
Chorus Parameter 10 LSB
:
16 2 00 – 7F
00 – 7F
Chorus Parameter 11 MSB
Chorus Parameter 11 LSB
:
18 2 00 – 7F
00 – 7F
Chorus Parameter 12 MSB
Chorus Parameter 12 LSB
:
1A 2 00 – 7F
00 – 7F
Chorus Parameter 13 MSB
Chorus Parameter 13 LSB
:
1C 2 00 – 7F
00 – 7F
Chorus Parameter 14 MSB
Chorus Parameter 14 LSB
:
1E 2 00 – 7F
00 – 7F
Chorus Parameter 15 MSB
Chorus Parameter 15 LSB
:
20 2 00 – 7F
00 – 7F
Chorus Parameter 16 MSB
Chorus Parameter 16 LSB
:
22 1 00 – 7F Chorus Return -∞dB – 0dB – +6dB
(0 – 96 – 127)
23 1 01 – 7F Chorus Pan L63 – C – R63
24 1 00 – 7F Send Chorus To Reverb -∞dB – 0dB (0 – 127)
4C 03 00 2 00 – 7F
00 – 7F
Insertion-A Type MSB
Insertion-A Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Insertion-A Parameter1 MSB
Insertion-A Parameter1 LSB
:
04 2 00 – 7F
00 – 7F
Insertion-A Parameter2 MSB
Insertion-A Parameter2 LSB
:
06 2 00 – 7F
00 – 7F
Insertion-A Parameter3 MSB
Insertion-A Parameter3 LSB
:
08 2 00 – 7F
00 – 7F
Insertion-A Parameter4 MSB
Insertion-A Parameter4 LSB
:
0A 2 00 – 7F
00 – 7F
Insertion-A Parameter5 MSB
Insertion-A Parameter5 LSB
:
0C 2 00 – 7F
00 – 7F
Insertion-A Parameter6 MSB
Insertion-A Parameter6 LSB
:
0E 2 00 – 7F
00 – 7F
Insertion-A Parameter7 MSB
Insertion-A Parameter7 LSB
:
10 2 00 – 7F
00 – 7F
Insertion-A Parameter8 MSB
Insertion-A Parameter8 LSB
:
12 2 00 – 7F
00 – 7F
Insertion-A Parameter9 MSB
Insertion-A Parameter9 LSB
:
14 2 00 – 7F
00 – 7F
Insertion-A Parameter10 MSB
Insertion-A Parameter10 LSB
:
16 2 00 – 7F
00 – 7F
Insertion-A Parameter11 MSB
Insertion-A Parameter11 LSB
:
18 2 00 – 7F
00 – 7F
Insertion-A Parameter12 MSB
Insertion-A Parameter12 LSB
:
1A 2 00 – 7F
00 – 7F
Insertion-A Parameter13 MSB
Insertion-A Parameter13 LSB
:
1C 2 00 – 7F
00 – 7F
Insertion-A Parameter14 MSB
Insertion-A Parameter14 LSB
:
1E 2 00 – 7F
00 – 7F
Insertion-A Parameter15 MSB
Insertion-A Parameter15 LSB
:
20 2 00 – 7F
00 – 7F
Insertion-A Parameter16 MSB
Insertion-A Parameter16 LSB
:
4C 04 00 2 00 – 7F Insertion-B Type MSB
Insertion-B Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F Insertion-B Parameter 1 MSB
Insertion-B Parameter 1 LSB
:
04 2 00 – 7F Insertion-B Parameter 2 MSB
Insertion-B Parameter 2 LSB
:
06 2 00 – 7F Insertion-B Parameter 3 MSB
Insertion-B Parameter 3 LSB
:
08 2 00 – 7F Insertion-B Parameter 4 MSB
Insertion-B Parameter 4 LSB
:
0A 2 00 – 7F Insertion-B Parameter 5 MSB
Insertion-B Parameter 5 LSB
:
0C 2 00 – 7F Insertion-B Parameter 6 MSB
Insertion-B Parameter 6 LSB
:
0E 2 00 – 7F Insertion-B Parameter 7 MSB
Insertion-B Parameter 7 LSB
:
10 2 00 – 7F Insertion-B Parameter 8 MSB
Insertion-B Parameter 8 LSB
:
12 2 00 – 7F Insertion-B Parameter 9 MSB
Insertion-B Parameter 9 LSB
:
14 2 00 – 7F Insertion-B Parameter 10 MSB
Insertion-B Parameter 10 LSB
:
16 2 00 – 7F
00 – 7F
Insertion-B Parameter 11 MSB
Insertion-B Parameter 11 LSB
:
18 2 00 – 7F
00 – 7F
Insertion-B Parameter 12 MSB
Insertion-B Parameter 12 LSB
:
1A 2 00 – 7F
00 – 7F
Insertion-B Parameter 13 MSB
Insertion-B Parameter 13 LSB
:
1C 2 00 – 7F
00 – 7F
Insertion-B Parameter 14 MSB
Insertion-B Parameter 14 LSB
:
1E 2 00 – 7F
00 – 7F
Insertion-B Parameter 15 MSB
Insertion-B Parameter 15 LSB
:
20 2 00 – 7F
00 – 7F
Insertion-B Parameter 16 MSB
Insertion-B Parameter 16 LSB
:
4C 05 00 1 00 – 0C Controller Set1 Source 0: PB, 1: MW, 3: AT, 4:FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
01 2 00
00 – 23
Controller Set1 Destination MSB
Controller Set1 Destination LSB
0 – 35
03 1 00 – 7F Controller Set1 Depth -64 – +63
04 1 reserved
05 1 00 – 0C Controller Set2 Source 0: PB, 1: MW, 3: AT, 4:FC,
5: FS, 6: RB, 7: BC, 8: AS1,
9: AS2, 12: FC2
06 2 00
00 – 23
Controller Set2 Destination MSB
Controller Set2 Destination LSB
0 – 35
08 1 00 – 7F Controller Set2 Depth -64 – +63
09 1 reserved
Data List
81
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
