Yamaha MOTIF ES6 Data List

TOTAL SIZE = 35 23 (HEX)
TOTAL SIZE = 68 44 (HEX)
MIDI PARAMETER CHANGE TABLE
(MIX COMMON for Pattern, Song)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
4C 10 00 1 00 – 7F Voice Bank MSB 0 – 127
01 1 00 – 7F Voice Bank LSB 0 – 127
02 1 00 – 7F Voice Number 0 – 127
03 1 28 – 58 Note Shift -24 – 0 – +24 [semitones]
04 1 00 – 7F Velocity Sense Depth 0 – 127
05 1 00 – 7F Velocity Sense Offset 0 – 127
06 1 00 – 7F (Vibrato Rate) LFO Speed -64 – +63
07 1 00 – 7F (Vibrato Depth) LFO Pitch Depth -64 – +63
08 1 00 – 7F (Vibrato Delay) LFO Delay -64 – +63
09 1 00 – 7F MW Filter Control -64 – +63
0A 1 reserved 0
0B 1 00 – 7F MW LFO Pitch Modulation Depth 0 – 127
0C 1 00 – 7F MW LFO Filter Modulation Depth 0 – 127
0D 1 00 – 7F MW LFO Amplitude Modulation
Depth
0 – 127
0E 1 28 – 58 CAT Pitch Control -24 – +24 [semitones]
0F 1 00 – 7F CAT Filter Control -64 – +63
10 1 reserved -64 – +63
11 1 00 – 7F CAT LFO Pitch Modulation Depth 0 – 127
12 1 00 – 7F CAT LFO Filter Modulation Depth 0 – 127
13 1 00 – 7F CAT LFO Amplitude Modulation
Depth
0 – 127
14 1 00 – 5F AC1 Controller Number 0 – 95
15 1 00 – 7F AC1 Filter Control -64 – +63
16 1 reserved -64 – +63
17 1 00 – 7F AC1 LFO Pitch Modulation Depth 0 – 127
18 1 00 – 7F AC1 LFO Filter Modulation Depth 0 – 127
19 1 00 – 7F AC1 LFO Amplitude Modulation
Depth
0 – 127
1A 1 00 – 7F Pitch EG Initial Level -64 – +63
1B 1 00 – 7F Pitch EG Attack Time -64 – +63
1C 1 00 – 7F Pitch EG Release Level -64 – +63
1D 1 00 – 7F Pitch EG Release Time -64 – +63
1E 1 00 – 7F EQ Low Gain -64 – +63 (-12 – +12 [dB])
1F 1 00 – 7F EQ High Gain -64 – +63 (-12 – +12 [dB])
20 1 04 – 28 EQ Low Frequency 32 – 2.0k [Hz]
21 1 1C – 3A EQ High Frequency 500 – 16.0k [Hz]
22 1 00 – 7F HPF Cutoff Frequency -64 – 0– +63
4C 20 00 64 00 – 7F Plug-in Board Native Parameter Depends on Plug-in Board
40 3 00 – 7F
00 – 7F
00 – 7F
Plug-in Board Type MSB
Plug-in Board Type LSB
Plug-in Board Version Number
43 1 00 – 7F reserved
Address Size Data
Range
(HEX)
Parameter Name Description Notes
36 00 00 1 reserved
01 1 reserved
02 1 reserved
03 1 reserved
04 1 reserved
05 1 reserved
06 1 reserved
07 1 reserved
08 1 reserved
09 1 reserved
0A 1 reserved
0B 1 reserved
0C 1 reserved
0D 1 reserved
0E 1 reserved
0F 1 reserved
10 1 reserved
11 1 00 – 01 ARP MIDI Out Switch off, on
12 1 00 – 10 ARP MIDI Out Channel 1 – 16, kbd-ch
36 00 13 1 reserved
14 2 00 – 7F
00 – 7F
ARP Type MSB
ARP Type LSB
0-1786: Preset,
8192-8447: User
16 1 00 – 01 ARP Switch off, on
17 1 00 – 02 ARP Hold sync-off, off, on
18 1 00 – 06 ARP Unit Multiplay 50%, 66%, 75%,
100%,133%, 150%, 200%
19 1 00 – 7F ARP Note Limit Low C-2 – G8
1A 1 00 – 7F ARP Note Limit High C-2 – G8
1B 1 01 – 7F ARP Velocity Limit Low 1 – 127
1C 1 01 – 7F ARP Velocity Limit High 1 – 127
1D 1 00 – 04 ARP Key Mode sort, thru, direct,
sort+direct, thru+direct
1E 1 00 – 01 ARP Vel Mode original, thru
1F 1 00 – 01 ARP Change Timing realtime, measure
20 1 00 – 06 ARP Quantize Value 32th, 16th Triplet, 16th, 8th
Triplet, 8th, 4th Triplet, 4th
21 1 00 – 64 ARP Quantize Strength 0 – 100%
22 2 0000 –
00C8
ARP Velocity Rate MSB
ARP Velocity Rate LSB
0 – 200%
24 2 0000 –
00C8
ARP Gate Time Rate MSB
ARP Gate Time Rate LSB
0 – 200%
26 2 ARP Swing MSB
ARP Swing LSB
-120 – 0 – +120
28 1 reserved
1 reserved
2A 2 0000 –
3FFF
ARP SF1 Assign Type MSB
ARP SF1 Assign Type LSB
0-1786: Preset,
8192-8447: User,
16383: No Type
2C 2 0000 –
3FFF
ARP SF2 Assign Type MSB
ARP SF2 Assign Type LSB
0-1786: Preset,
8192-8447: User,
16383: No Type
2E 2 0000 –
3FFF
ARP SF3 Assign Type MSB
ARP SF3 Assign Type LSB
0 -1 786: Preset,
8192 – 8447: User,
16383: No Type
30 2 0000 –
3FFF
ARP SF4 Assign Type MSB
ARP SF4 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
32 2 0000 –
3FFF
ARP SF5 Assign Type MSB
ARP SF5 Assign Type LSB
0 – 1786: Preset,
8192 – 8447: User,
16383: No Type
36 00 34 1 00 – 05 Knob Function Select 0=Pan&Send, 1=Tone,
2=Assign, 3=PartEQ,
4=MasterEffect, 5=ARP FX
35 1 reserved
36 1 reserved
37 1 reserved
38 1 reserved
39 1 reserved
3A 1 reserved
3B 1 reserved
3C 1 reserved
3D 1 reserved
3E 1 00 – 7F KnobA -64 – +63
3F 1 00 – 7F KnobB -64 – +63
40 1 reserved
41 1 00 – 7F EQ Low Gain -64 – +63
42 1 00 – 7F EQ Low Mid Gain -64 – +63
43 1 00 – 7F EQ High Mid Gain -64 – +63
44 1 00 – 7F EQ High Gain -64 – +63
45 1 00 – 7F Assign1 -64 – +63
46 1 00 – 7F Assign2 -64 – +63
47 1 reserved
48 1 reserved
49 1 reserved
4A 1 reserved
4B 1 reserved
4C 1 reserved
4D 1 reserved
4E 1 reserved
4F 1 reserved
50 1 reserved
51 1 reserved
36 00 52 1 reserved
53 1 reserved
54 1 reserved
55 1 reserved
56 1 reserved
57 1 reserved
58 1 00 – 5F Assign1 Control Number off, 1 – 95
59 1 00 – 5F Assign2 Control Number off, 1 – 95
5A 1 00 – 5F BC Control Number off, 1 – 95
5B 1 00 – 5F FC2 Control Number off, 1 – 95
5C 1 00 – 5F FC1 Control Number off, 1 – 95
5D 1 00 – 01 RB Mode hold, reset
5E 1 00 – 5F RB Control Number off,1 – 95
5F 1 01 – 02 Analog Insertion Connect Type A->B, B->A
Address Size Data
Range
(HEX)
Parameter Name Description Notes
82
Data List
MIDI Data Table

Yamaha MOTIF ES6 Specifications

General

Keyboard	61 keys, Initial Touch/Aftertouch
Polyphony	128 notes
Display	240 x 64 dot backlit LCD
Wave ROM	175MB (when converted to 16-bit linear format)
Sequencer	16 Tracks, Approx. 226, 000 notes
Arpeggiator	1, 787 types
Connectors	MIDI In/Out/Thru, USB, Foot Controller, Foot Switch
Power Supply	AC Adaptor (PA-300 or an equivalent recommended by Yamaha)
Storage	SmartMedia
User Voices	128 normal voices + 32 drum kits
