TOTAL SIZE = 20 14 (HEX)
TOTAL SIZE = 35 23 (HEX)
TOTAL SIZE = 68 44 (HEX)
Address Size Data
Range
(HEX)
Parameter Name Description Notes
36 10 00 1 34 – 4C EQ Gain1 -12 – +12 [dB]
01 1 04 – 28 EQ Frequency1 32 – 2000 [Hz]
02 1 01 – 78 EQ Q1 0.1 – 12.0
03 1 00 – 01 EQ Shape1 shelv, peak
04 1 34 – 4C EQ Gain2 -12 – +12 [dB]
05 1 0E – 36 EQ Frequency2 100 – 10.0 [kHz]
06 1 01 – 78 EQ Q2 0.1 – 12.0
1 01 EQ SHAPE2 PEAKING reserved
08 1 34 – 4C EQ Gain3 -12 – +12 [dB]
09 1 0E – 36 EQ Frequency3 100 – 10.0 [kHz]
0A 1 01 – 78 EQ Q3 0. 1- 12.0
1 Not Used
0C 1 34 – 4C EQ Gain4 -12 – +12 [dB]
0D 1 0E – 36 EQ Frequency4 100 – 10.0 [kHz]
0E 1 01 – 78 EQ Q4 0.1 – 12.0
1 Not Used
10 1 34 – 4C EQ Gain5 -12 – +12 [dB]
11 1 1C – 3A EQ Frequency5 0.5 – 16.0 [kHz]
12 1 01 – 78 EQ Q5 0.1 – 12.0
13 1 00 – 01 EQ Shape5 shelv, peak
36 11 00 2 00 – 7F
00 – 7F
Master Effect Type MSB
Master Effect Type LSB
Refer to “Effect Parameter
List.”
02 2 00 – 7F
00 – 7F
Master Effect Parameter1 MSB
Master Effect Parameter1 LSB
:
04 2 00 – 7F
00 – 7F
Master Effect Parameter2 MSB
Master Effect Parameter2 LSB
:
06 2 00 – 7F
00 – 7F
Master Effect Parameter3 MSB
Master Effect Parameter3 LSB
:
08 2 00 – 7F
00 – 7F
Master Effect Parameter4 MSB
Master Effect Parameter4 LSB
:
0A 2 00 – 7F
00 – 7F
Master Effect Parameter5 MSB
Master Effect Parameter5 LSB
:
0C 2 00 – 7F
00 – 7F
Master Effect Parameter6 MSB
Master Effect Parameter6 LSB
:
0E 2 00 – 7F
00 – 7F
Master Effect Parameter7 MSB
Master Effect Parameter7 LSB
:
10 2 00 – 7F
00 – 7F
Master Effect Parameter8 MSB
Master Effect Parameter8 LSB
:
12 2 00 – 7F
00 – 7F
Master Effect Parameter9 MSB
Master EffectParameter9 LSB
:
14 2 00 – 7F
00 – 7F
Master Effect Parameter10 MSB
Master Effect Parameter10 LSB
:
16 2 00 – 7F
00 – 7F
Master Effect Parameter11 MSB
Master Effect Parameter11 LSB
:
18 2 00 – 7F
00 – 7F
Master Effect Parameter12 MSB
Master Effect Parameter12 LSB
:
1A 2 00 – 7F
00 – 7F
Master Effect Parameter13 MSB
Master Effect Parameter13 LSB
:
1C 2 00 – 7F
00 – 7F
Master Effect Parameter14 MSB
Master Effect Parameter14 LSB
:
1E 2 00 – 7F
00 – 7F
Master Effect Parameter15 MSB
Master Effect Parameter15 LSB
:
20 2 00 – 7F
00 – 7F
Master Effect Parameter16 MSB
Master Effect Parameter16 LSB
:
22 1 00 – 01 Master Effect ON/OFF 0: OFF, 1: ON
36 20 00 16 00 – 7F Plug-in Board Native System
Parameter
(for InsEF Plug-in)
10 48 00 – 7F Plug-in Board Native Parameter (for InsEF Plug-in)
40 3 00 – 7F Plug-in Board Type MSB
Plug-in Board Type LSB
Plug-in Board Version Number
(for InsEF Plug-in)
43 1 00 – 7F reserved
MIDI PARAMETER CHANGE TABLE (MIX PART for Pattern, Song)
Address Size Data Range
(HEX)
Parameter Name Description Notes
37 pp 00 1 00 – 7F Bank Select MSB 0 – 127
01 1 00 – 7F Bank Select LSB 0 – 127
02 1 00 – 7F Program Number 1 – 128
03 1 00 – 0F, 7F Receive Channel 1 – 16, off (7F)
04 1 00 – 01 Part Mode mono, poly
05 1 01 – 7F Velocity Limit Low 1 – 127
06 1 01 – 7F Velocity Limit High 1 – 127
07 1 00 – 7F Note Limit Low C-2 – G8
08 1 00 – 7F Note Limit High C-2 – G8
09 1 10 – 58 Pitch Bend Range Upper -48 – +24 (PB Part: -24 – +24)
0A 1 10 – 58 Pitch Bend Range Lower -48 – +24
0B 1 00 – 7F Velocity Sense Depth 0 – 127
0C 1 00 – 7F Velocity Sense Offset 0 – 127
0D 1 00 – 7F Volume 0 – 127
0E 1 01 – 7F Pan L63 – C – R63
0F 1 reserved
10 2 00 – 0F
00 – 0F
Detune MSB
Detune LSB
-12.8 – +12.7 [Hz]
1st bit3-0 bit7-4
2nd bit3-0 bit3-0
12 1 00 – 7F Reverb Send 0 – 127
13 1 00 – 7F Chorus Send 0 – 127
14 1 00 – 7F reserved
15 1 00 – 7F Dry Level 0 – 127
16 1 28 – 58 Note Shift -24 – +24 [semitones]
17 1 00 – 7F Filter Cutoff Frequency -64 – +63
18 1 00 – 7F Filter Resonance/Width -64 – +63
19 1 reserved
1A 1 00 – 01 Portamento Switch off, on
1B 1 00 – 7F Portamento Time 0 – 127
1C 1 00 – 01 Portamento Mode fingered, fulltime
1D 1 reserved
1E 1 00 – 7F Output Select 0: L&R
8: asnL&R,
9-15: asn1&2 – asn13&14
64 – 79: asnL, asnR, asn1 – asn14
127: drum (or L&R)
Fixed to L&R for parts 17 - 32.
37 pp 1F 1 00 – 7F reserved
Arpeggio Sw
Receive Control Change
Receive Bank Select
Receive Program Change
Receive AT
Receive PB
bit0: reserved
bit1: Arpeggio Sw off, on
bit2: off, on Control Change
bit3: off, on Bank Select
bit4: off, on Program Change
bit5: off, on AT
bit6: off, on PB
84
Data List
MIDI Data Table
