Yamaha MOTIF ES6 Data List

TOTAL SIZE = 58 3A (HEX)
pp = part number
00 – 0F Part 1 – 16 (Normal, Drum, Sample)
60 Part Plug-in 1 (User, Preset, Direct)
61 Part Plug-in 2 (User, Preset, Direct)
62 Part Plug-in 3 (User, Preset, Direct)
10 – 1F Multi Plug-in Board Part (Not included in the Mixing setup)
TOTAL SIZE = 8 08 (HEX)
pp = part number
40 – 44 AD Part
20 1 00 – 7F Receive Volume/Expression
Receive Pan
Receive Sustain/Sostenuto
Receive MW
bit0: off, on Volume/Expression
bit1: off, on Pan
bit2: reserved
bit3: off, on Sustain/Sostenuto
bit4: reserved
bit5: off, on MW
bit6: reserved
21 1 00 – 7F Receive FC2
Receive FS
Receive FC1
Receive BC
Receive Knob1
Receive Knob2
Receive RB
bit0: off, on FC2
bit1: off, on FS
bit2: off, on FC1
bit3: off, on BC
bit4: off, on KN1
bit5: off, on KN2
bit6: off, on RB
37 pp 22 1 00 – 7F AEG Decay2 Level (EG Sustain Level) -64 – +63
23 1 00 – 7F AEG Attack Time (EG Attack Time) -64 – +63
24 1 00 – 01 Voice Pan on/off off, on
25 1 00 – 7F AEG Decay2 Time (EG Decay Time) -64 – +63
26 1 00 – 7F AEG Release Time (EG Release Time) -64 – +63
27 1 00 – 7F FEG Decay2 Level (EG Sustain Level) -64 – +63
28 1 00 – 7F FEG Attack Time (EG Attack Time) -64 – +63
29 1 reserved
2A 1 00 – 7F FEG Decay2 Time (EG Decay Time) -64 – +63
2B 1 00 – 7F FEG Release Time (EG Release Time) -64 – +63
2C 1 00 – 7F FEG DEPTH -64 – +63
37 pp 2D 1 reserved
2E 2 002E – 00B6 Low Frequency MSB
Low Frequency LSB
50.1 – 2.00k
30 1 20 – 60 Low Gain -32 – +32
31 1 reserved
32 2 0053 – 00F1 Mid Frequency MSB
Mid Frequency LSB
139.7 – 10.1k
34 1 20 – 60 Mid Gain -32 – +32
35 1 00 – 1F Mid Resonance 0 – 31
36 2 0083 – 00FF High Frequency MSB
High Frequency LSB
503.8 – 14k
38 1 20 – 60 High Gain -32 – +32
39 1 reserved
Address Size Data Range
(HEX)
Parameter Name Description Notes
38 pp 00 1 00 – 03 A/D Input Mode L mono, R mono, L+R mono, stereo
01 1 00 – 7F A/D Part Volume 0 – 127
02 1 01 – 7F A/D Part Pan L63 – C – R63
03 1 00 – 7F A/D Part Reverb Send 0 – 127
04 1 00 – 7F A/D Part Chorus Send 0 – 127
05 1 00 – 7F reserved
06 1 00 – 7F A/D Part Dry Level 0 – 127
07 1 00 – 4F A/D Part Output Select 0: L&R
8: asnL&R
9-15: asn1&2 – asn13&14
64 – 79: asnL, asnR, asn1 – asn14
Address Size Data Range
(HEX)
Parameter Name Description Notes
Data List
85
MIDI Data Table
