Specications
Main Specications
System Type Powered speaker
Frequency Response (-10 dB) 67 Hz - 22 kHz
Crossover Frequency 4 kHz
Maximum Output Level (Measured peak, IEC noise@1m) 99 dB SPL
Power Requirements
*1
110 - 240 V, 50/60 Hz
Power Consumption 30 W
Dimensions (W x H x D) System (maximum) 144 x 236 x 166 mm
Weight 3.6 kg
Amplier section
Maximum Output THD 0.1%, 1kHz, RL=4 Ω 22 W
Input Sensitivity
Input Sensitivity, Input Impedance LINE 1 : -10 dBu, 10 kΩ (RCA)
Input Sensitivity, Input Impedance LINE 2 : +4.0 dBu, 10 kΩ (COMBO)
Input Connectors
LINE 1 : RCA
LINE 2 : COMBO (XLR/PHONE)
Level control LINE1, LINE2
Tone Control
Characteristic
LOW = CENTER
REF = 100 Hz, 2 V
MIN -3.0 ± 2.0 dB
MAX +3.0 ± 2.0 dB
HIGH = CENTER
REF = 10 kHz, 2 V
MIN -3.0 ± 2.0 dB
MAX +3.0 ± 2.0 dB
Indicator Green LED
Speaker section
Enclosure 2Way, Bass-reflex type
Speaker Unit
HF (Tweeter) : 0.8" (2.2 cm) Dome
LF (Woofer) : 4" (10 cm) Cone
Accessories
Included in the package Power cord x1, Owner’s Manual
*1: Make sure to use this product at the supply voltage indicated on the rear panel of this product.
* The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest
manual, access the Yamaha website then download the manual file.
