DESCRIPTION
2-3
2
EAU10431
Controls and instruments
1. Clutch lever (page 3-14)
2. Left handlebar switches (page 3-13)
3. Multi-function meter unit (page 3-6)
4. Main switch/steering lock (page 3-2)
5. Front brake fluid reservoir (page 6-21)
6. Right handlebar switches (page 3-13)
7. Throttle grip (page 6-15)
8. Brake lever (page 3-14)
U1WSE0E0.book Page 3 Wednesday, November 13, 2013 10:28 AM
