General| Displacement | 889cc |
|---|---|
| Bore x Stroke | 78.0 mm x 62.1 mm |
| Compression Ratio | 11.5:1 |
| Fuel System | Fuel Injection |
| Transmission | 6-speed |
| Final Drive | Chain |
| Frame | Diamond |
| Rear Brake | Hydraulic single disc, Ø245 mm |
| Front Tire | 120/70ZR17 M/C (58W) |
| Rear Tire | 180/55ZR17 M/C (73W) |
| Overall Length | 2, 090 mm |
| Overall Height | 1, 190 mm |
| Seat Height | 825 mm |
| Wheelbase | 1, 430 mm |
| Ground Clearance | 140 mm |
| Fuel Capacity | 14 L |
| Wet Weight | 189 kg |
| Lubrication System | Wet sump |
| Ignition System | TCI |
| Starter System | Electric |
| Fuel Consumption | 5.0 L/100 km |
| Oil Tank Capacity | 3.5 L |
| Caster Angle | 25° |
| Front Travel | 130 mm |
| Rear Travel | 122 mm |
| Engine Type | Liquid-cooled, 4-stroke, DOHC, 3-cylinder |
| Maximum Power | 87.5 kW (119.0 PS) @ 10, 000 rpm |
| Maximum Torque | 93 Nm (9.5 kg-m) @ 7, 000 rpm |
| Front Suspension | 41mm KYB inverted fork |
| Front Brake | Dual hydraulic disc, Ø298 mm |
| Clutch Type | Wet, multiple-disc |
| Overall Width | 31.9 in (810 mm) |
